Operation Manual – User Access
H3C SecPath Series Security Products
Table 1-9 Assign directly the specified IP address for the peer on the interface
Assign an IP address for the PPP user
Remove the configuration
By default, if the remote address pool command and the domain address pool are not
configured, the specified IP address is not assigned for the peer on the interface.
Method 2: Assign an IP address for the peer using a global address pool
Define a global address pool in system view first, and then use the remote address
pool command on the interface to specify a global address pool number (only one
number can be specified).
Table 1-10 Assign an IP address for the peer using a global address pool
Define a global IP address pool
Remove the configuration
Use the global address pool to assign an
IP address for the PPP user
Remove the configuration
By default, if the remote address pool command and the domain address pool are not
configured, the IP address is not assigned for the peer. When you configure the remote
address pool command but do not configure the pool-number parameter, the system
uses global address pool 0 by default.
If you do not authenticate the PPP user, you can use methods 1 and 2. If you need to
authenticate the PPP user, you should use method 3 as follows:
Method 3: Assign an IP address for the peer using the address pool for the domain
Define a address pool for the domain in domain view first, and then use the remote
address pool command to specify the address pool number for the domain (you can
specify only one number); if you do not configure the remote address pool command,
use the address pools of the corresponding domains in turn to assign IP addresses for
users during authentication negotiation.
Operation
Operation
1-9
Chapter 1 PPP Configuration
Command
remote address ip-address
undo remote address
Command
ip pool pool-number low-ip-address
[ high-ip-address ]
undo ip pool pool-number
remote address pool [ pool-number ]
undo remote address
