JSI Reef Installation Instructions

Reef
Recommended Tools
Level
#2 Phillips Screw Driver
Package Contents
Shelves
Stretcher Rails
Step 1
Attach Stretcher Rails to End Panels
• Stand End Panels upright and attach Stretcher Rail
using 1 " bolts. Do not tighten bolts firmly until both
/
4
Stretcher Rails are in place.
• After both Stretcher Rails are placed, tighten bolts firmly.
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
Screw Gun
Socket
Wrench
7 / " Socket
16
Top
End Panels
Insert bolts; Keep bolts
loose until both Stretcher
Rails are in place
jsifurniture.com 812.482.3204
800.457.4511 812.482.1548
#2 Phillips Head Bit
3 " Hex Wrench
/
16
Note: Two people are recommended for assembly.
Bookshelf Center
Panel; remove for
easier access.
225 Clay Street / PO Box 231
O
Jasper, Indiana 47546
F

Installation Instructions

Layered Table with Bookshelf
Hardware Used
#8 x 5 " Flat Head Wood Screws
/
8
#8 x 5 " Pan Head Wood Screws
/
8
1/4 x 1 " Machine Bolts
1/4 - 20 x 3 " Socket Head Cap Screws
/
4
(Used with Foot Rail option)
Tighten bolts firmly once both
Stretcher Rails are in place.
Page 1 of 3
Form No. INST-RE003
5/1/16
