Entering Alpha Characters

To enter an alpha character, press the number
key that has the desired letter below it. The
keypad display shows the number on that key.
To change the number to a letter, press the top
row select key that corresponds to the letter
location under the key. See Figure 8.

Entering Non-Alphanumeric Characters

Each key has a non-alpha special character
that is not shown on the keypad. Non-
alphanumeric characters are entered into the
keypad the same way as alphanumeric characters.
See Figure 9.
14
Keypad Interface
A
First Letter
Figure 8: Entering Alpha Characters
1
5
9
Non-Alphanumeric Characters
B C
Third Letter
Special Character
Second Letter
2 3
6 7
0
Figure 9: Entering
(
4
8
CMD
