DMP Electronics THINLINE Series Installation Manual page 8

Surface and Backbox
Combined 4-square
and 3-gang switch box
Mounting Holes
Surface and Backbox
6
Mounting Holes
Mounting Holes
Figure 3: Keypad Back Showing Wiring
Install the Keypad
Green/White
– Connect Reader Data 0
White
– Connect Reader Data 1
Orange
– Door Strike N/O
–
Gray
Door Strike C
–
Violet
Door Strike N/C
Yellow/White
1K EOL
White/Yellow
Orange White
1K EOL
White/Orange
Red/White
1K EOL
White/Red
Brown/White
1K EOL
White/Brown
Black
– Ground
Green
– Receive Data
Yellow
– Send Data
Red
– Keypad Power
*All zones are supervised and suitable for fire applications.
*Maximum zone line impedence is 100 Ohms.
*Ground fault detected at 1420 Ohms or less.
Harness Assignments
ExternalReader/Door Strike
7073/7073A, 7173 Keypads
– Zone 4
Zones 1-4
– Zone 3
7070/7070A, 7073/7073A, 7170/7173 Keypads
– Zone 2
– Zone 1
All Keypads
