Operation Flow - MicroStep SH-HC30 User Manual

Usually, the I/O of the CNC system is in manual control mode of t he height controller.
When processing starts, the I/O of the CNC system will turn t o aut omatic control mode of
the height controller. In such mode, the mecha nical lifting device of the height controller is
under automatic height control.
4.3 Operation via communication interface of CNC system (RS232
communication mode)
This feature is under development and will be amended aft er the functions are completed.
4.4

Operation Flow

For mechanical installation,
see 3.1 and connection of
capacitance sensor is
For electrical connection in
arc voltage mode, see 3.3
Power on and set the
detection mode to arc
voltage mode, see 5.1
and 7.1
PDF 文件使用 "pdfFactory Pro" 试用版本创建
调高器说明书
Flow starts
Arc
voltage detection m ode
required.
The flow ends.
www.fine print.com.cn
capacitance
For mechanical installation,
see 3.1 and connection of
capacitance sensor is
required.
For electrical connection in
capacitance mode, see 3.2
Power on and set the
detection mode to
capacitance mode, see
5.1 and 7.1
28
