7.1 Control Parameters

Set value ( A: Accuracy Height): the expected value of the distance (height) between the
cutting nozzle and the work piece, which is set by user. For the set range and factory
default value, see Table 7-1.
Dead zone value (E: Erro r Area): When the actual height is A ± E, the height of cutting
torch will not be adj ustable any more (see 1.4). For t he set range and fact ory default
value, see Table 7-1
Speed regulating zone ( d: Down Speed Area): the t wo speed regulating zones are
between A-E-d and A- E as well as between A + E and A + E + d (see 1.4). For t he set
range and factory default value, see Table 7-1.
High limit point (H: High Limit): W hen the cutting torch position is higher than this
set value, an alarm will pop up and the cutting torch can not move up further. For the
set range and default value, see Table 7-1.
Low limit point (L: Low Limit ): When the cutting torch is lower than this set value, an
alarm will pop up and t he cutt ing t orch can not move down further. For the set range
and factory default value, see Table 7-1.
Selection of detector (C: capacitance): 0 is for arc voltage detection and 1 is for
capacitive detect ion. For t he set range and factory default value, see Table 7-1.
No board drop para meter (b):
In capacitive detect ion mode, when the detect ed height is higher t han value b, the
cutting torch will descending stop descending; when t he height becomes lower than
value b, automatic height control will be enabled again;
In arc voltage detection mode, when cutting torch is moving down manually and
encounters the zero-point signal, the cutt ing t orch will move up to b mm. For the set
range and factory default value, see Table 7-1.
