DISPLAY – Image Modes
Switch HDMI:
The screen will switch back-and-forth
from the HDMI input to the camera image at set time
intervals
Camera VOV Switch:
The screen will display the SD
Card content in the corner of the screen at set time
intervals over the camera image.
Alarm VOV:
SD Card content will be full screen until
triggered by the Alarm Input— when triggered, a
"Return to Cashier" message will flash on the screen.
SD CARD
Basic Setup Guide: CE-M21A-PIR / CE-M27A-PIR / CE-M32A-PIR
02.08.19
*continued
Switch SD Video:
forth from the camera image to the SD Card content at
set time intervals.
SD CARD
Motion VOV:
no motion, when motion is detected by the PIR sensor
the SD Card content will be shown over the camera in
the corner of the screen.
SD CARD
Alarm:
The camera image will be on the screen until
triggered by the Alarm Input— when triggered, a
"Return to Cashier" message will flash on the screen.
3
The screen will switch back-and-
The camera image will be full screen with
Information in this document is subject to change without notice.
SD CARD
