Clinton Electronics CE-L07 User Manual

CE-L07
MODE TCON VOL
Remove Protective Film
1
Peel o the protective film from the front of the LCD screen. You can also remove the plastic battery-retention-tab from the remote
control at this time if desired.
Attach Stand / Wall Mount
2
Lay the display face down on a clean, flat surface. Position
the narrow rounded end of the stand into the slot on the
back of the display. Using the included attachment screws,
screw the stand onto the display. Attach the square side of
the bracket to your mounting surface using appropriate
screws (not included).
• KEEP THE PLASTIC PACKAGING OUT OF THE REACH OF CHILDREN. CHILDREN MAY SUFFOCATE. DO NOT INSTALL
THE PRODUCT WITHIN THE REACH OF YOUNG CHILDREN.
• DO NOT EXPOSE THE PRODUCT TO DIRECT SUNLIGHT, HEAT, OR A HOT OBJECT SUCH AS A STOVE. PRODUCT
LIFESPAN MAY BE REDUCED OR A FIRE MAY RESULT.
• DO NOT INSTALL THE PRODUCT IN A VEHICLE OR A PLACE EXPOSED TO DUST, MOISTURE (WATER DRIPS, ETC.),
OIL, OR SMOKE. A FIRE OR ELECTRIC SHOCK MAY RESULT.
VOL MENU SOURCE
*Information in this document is subject to change
ITEMS INCLUDED
• Monitor
LCD REMOTE
• AC-to-DC Power Supply (5' Cord)
• 12V DC Automobile Power Supply (5' Cord)
VIDEO
• 12V Pigtail Adapter
SELECT
• Remote Control
MENU
• 5' Composite A/V Cable (BNC/RCA to 3.5mm)
MODE
SELECT
• 5' HDMI Cable
• Tilting Stand / Wall Mount
• Installation Guide
Adjust Angle
3
The stand can be table mounted, or wall mounted flush.
To adjust, simply move the display to the desired
angle. The bracket has the correct tension to move by
hand without the need to tighten or loosen the nuts.

USER MANUAL

v.10.29.15
