HD Series PVMs
Camera On Screen Display
User Manual
Make sure you read this manual before using the
camera. Store this manual safely so that you can use
it in the future. Please use this manual along with
the Installation Manual included with the camera.
Clinton Electronics Corp. 6701 Clinton Road. Loves Park, IL 61111
Sales: 1-800-447-3306 Support: 1-800-549-6393 www.clintonelectronics.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clinton Electronics HD series
Summary of Contents for Clinton Electronics HD series
-
Page 1: User Manual
Store this manual safely so that you can use it in the future. Please use this manual along with the Installation Manual included with the camera. Clinton Electronics Corp. 6701 Clinton Road. Loves Park, IL 61111 Sales: 1-800-447-3306 Support: 1-800-549-6393 www.clintonelectronics.com... -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS walked on or pinched particularly at Read these instructions. plugs, convenience receptacles, and the point where they exit from the ap- Keep these instructions. paratus. Heed all warnings. Only use attachments/accessories specified by the manufacturer. Follow all instructions. Use only with the cart, stand, tri- Do not use this apparatus near water. - Page 3 DISCLAIMER: Clinton Electronics reserves the right to change the contents of this manual without prior notice. WARNING: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
- Page 4 The camera requires periodic Stop using your camera if you find it inspection. malfunctioning. Contact an authorized technician to carry If the camera emits smoke or is unusually out the inspection. hot for a long period, a fire may be caused. Do not install the camera on a surface Do not hold plug with wet hands.
-
Page 5: Table Of Contents
TABLE OF CONTENTS ON SCREEN DISPLAY MENU 01-03 OSD MENU SETTINGS ZOOM FOCUS 05-06 LENS EXPOSURE BACKLIGHT 09-10 DAY & NIGHT WHITE BAL DNR (Digital Noise Reduction) IMAGE 14-15 DIS (Digital Image Stabilization) MOTION 17-18 SYSTEM 19-20 EXIT TROUBLESHOOTING... -
Page 6: ( On Screen Display ) Menu
• PRIVACY • ON • OFF MOTION • ON • OFF • COMM • MODE SEL • FRAME RATE SYSTEM • SYSTEM • LANGUAGE • CAM TITLE • RESET EXIT • RETURN Clinton Electronics Corp. HD Series PVMs User Manual... - Page 7 PVM) or on older models can be adjusted with the button pad (located inside the camera access door). Joystick use: Press the ‘IN’ on the joystick to activate the OSD menu. Button pad use: Press the SET button to activate the OSD menu. Clinton Electronics Corp. HD Series PVMs User Manual...
- Page 8 DAY&NIGHT AUTO WHITE BAL MIDDLE IMAGE MOTION SYSTEM EXIT MENU 21” ~ 43” with Autofocus Lens: ZOOMFOCUS Additional ZOOMFOCUS menu. LENS EXPOSURE BACKLIGHT AUTO DAY&NIGHT WHITE BAL MIDDLE IMAGE MOTION SYSTEM EXIT Clinton Electronics Corp. HD Series PVMs User Manual...
-
Page 9: Osd Menu Settings
• An item with the “ - - - ” icon is unavailable due to function settings. • All menu items have a ‘RETURN’ option. With this function you have the option to ‘RET’ (RETURN), which takes you back to the previous menu screen. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 10: Zoom Focus
• HALF: The lens scans only the current focal length, taking about 15 seconds. • FULL: The lens scans the entire focal length, taking 30 seconds or longer. Scanning Mode: Half Full One Shot 5 seconds 15 seconds Lens Reset 15 seconds 30 seconds Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 11: Zoom Focus
– the camera might focus on those objects and could appear out of focus. To refocus the camera either adjust the level of zoom (zoom in / zoom out) or press and hold on ONESHOT. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 12: Lens
LENS These settings are not user adjustable. MENU LENS MANUAL EXPOSURE BACKLIGHT DAY&NIGHT AUTO WHITE BAL MIDDLE IMAGE MOTION SYSTEM EXIT Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 13: Exposure
• The higher the SENS-UP level, the brighter the screen, but the more likely it is that an after-image will appear. Possible image blur is normal with increased zoom while using SENS-UP. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 14: Backlight
• LEVEL: The lower the level, the more of the HLC mask will be applied. • COLOR: Black, White, Yellow, Cyan, Green, Magenta, Red, and Blue. HLC ON HLC OFF Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 15: Backlight
• WEIGHT: Set to LOW, MIDDLE or HIGH. WDR ON WDR OFF Notes • When WDR is turned ‘ON’ certain OSD menu options are disabled. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 16: Day & Night
► COLOR The image is always displayed in color. Automatic switching does not occur. ► B/W The image is always displayed in black and white. Automatic switching does not occur. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 17: White Bal
2. When the ambient illumination of the subject is dim. 3. If the camera is directed towards a fluorescent light or is installed in a place where illumination changes dramatically, the WHITE BALANCE operation may become unstable. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 18: Dnr (Digital Noise Reduction)
• When adjusting the noise reduction level, remember that the higher the level is set, the greater the reduction in noise level, as well as the brightness of the image but trailing may occur with moving objects. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 19: Image
► GAMMA Adjust how light and color are displayed. ► MIRROR Mirror the camera image horizontally. ► FLIP Flip the camera image vertically. MIRROR FLIP MIRROR & FLIP (rotate 180°) Clinton Electronics Corp. HD Series PVMs User Manual... - Page 20 • Picture quality degrades when using the digital zoom functions. • E. Zoom is disabled when Motion/Quick Zoom is turned ON. • ACE & Defog are disabled when WDR is turned ON. Clinton Electronics Corp. HD Series PVMs User Manual...
-
Page 21: Dis (Digital Image Stabilization)
• When DIS is turned on, the image is zoomed in digitally. Depending on the zoom level (Range%) set, certain camera OSD overlays like Privacy and Motion boxes will be zoomed in also– possibly off the screen. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 22: Motion
When a motion type is detected a signal is output from the camera. This must be set to ON for the motion detection signal from the camera to trigger switching of sources. Clinton Electronics Corp. HD Series PVMs User Manual... - Page 23 • The same image shown on the screen will be output to a connected DVR. Do not turn on Motion Tracker & Quick Zoom if you do not want the recorded video to have colored lines and zoom in & out. Clinton Electronics Corp. HD Series PVMs User Manual...
-
Page 24: System
In North America leave set to NTSC. ► LANGUAGE Change the language of the OSD Menu. • ENGLISH, CHINESE, CHINESE (S), JAPANESE or KOREAN Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 25: Exit
• When the CAM TITLE menu is ‘OFF’, no title will be displayed on the monitor even if you enter one. EXIT From the main menu, scroll to EXIT and press IN on the joystick to exit from the OSD menu. Clinton Electronics Corp. HD Series PVMs User Manual... -
Page 26: Troubleshooting
TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact Clinton Electronics Technical Support at 1-800-549-6393 or 815-633-1444. Problem Solution Nothing appears on the • Check the power connection. - Page 27 • Check the DAY&NIGHT setting. If the camera to B/W mode at night. is equipped with IRs, leave set to EXTERN. SENS-UP function is not • Check if Shutter settings are set to AUTO working. or 1/30. Clinton Electronics Corp. HD Series PVMs User Manual...
- Page 28 To change the digital video output of the camera (SDI Output): Enter the cam- era’s OSD menu– then access the SYSTEM menu, scroll to MODE SEL and move left or right to change from HD-SDI to EX-SDI. Clinton Electronics Corp. HD Series PVMs User Manual...
- Page 29 CONTACT Clinton Electronics Corp. HD Series PVMs User Manual...
- Page 30 Clinton Electronics Corp. 6701 Clinton Road. Loves Park, IL 61111 Sales: 1-800-447-3306 Support: 1-800-549-6393 www.clintonelectronics.com ver: 11.01.17...
