DISPLAY – Image Modes
Press the 'MENU' button on the included remote or the buttons located on the back of the PVM to adjust menu
settings. Navigate up/down through the menu, press Enter to select an option and left/right to make adjustments.
Press the Exit button to escape from a menu option and to exit the OSD menu.
Camera: Only the camera image is shown on the
screen of the PVM, no switching occurs.
SD Video: Only content (images or video) from the
SD Card player is shown on the screen, no switching
occurs.
SD CARD
Basic Setup Guide: CE-M21A-PIR / CE-M27A-PIR / CE-M32A-PIR
02.08.19
Display
Aspect Ratio
Image Mode
Motion Dwell Time
Camera
HDMI:
screen of the PVM, no switching occurs.
Motion:
SD Card will be shown on the screen, when motion is
detected by the PIR sensor the screen will switch to
the camera image.
2
: Full Screen
: Motion
: 5 Sec.
1920x1080@30Hz
Only a connected HDMI input is shown on the
When no motion is detected content from the
SD CARD
