Summary of Contents for Clinton Electronics CE-M10A
- Page 1 Public View Monitor Manual CE-M10A v08.15.16 6701 Clinton Road Loves Park, IL 61111 | 800.447.3306 (Sales) | 800.549.6393 (Support) | www. clintonelectronics.com...
-
Page 2: Table Of Contents
Warning & Compliance Important Safeguards Hardware Overview PVM Exterior Back Panel Connections Remote Control Display Menu OSD Menu Overview Video Menu Display Menu Image Modes Audio Menu System Settings SD Card Camera Software IP Installer - Windows 13-14 Web Viewer - Mac OSX 15-16... -
Page 3: Warning & Compliance
The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) -
Page 4: Important Safeguards
1. Read Instructions If the equipment does not operate normally by All the safety and operating instructions should be following the operating instructions, adjust only read before the appliance is operated. those controls that are covered by the operating instructions as an improper adjustment of other 2. -
Page 5: Hardware Overview
Hardware Overview... -
Page 6: Pvm Exterior
FRONT CAMERA VIDEO SD MEMORY DO NOT REMOVE - CIF Memory Camera Lens Remote Receiver LED Flasher BACK DC24V OUTPUT (POE) VIDEO SD MEMORY DO NOT REMOVE - CIF Memory VESA 100 VESA 75 CAMERA... -
Page 7: Back Panel Connections
BACK PANEL DC 24V DC 24V Input INPUT BNC Out OUTPUT Network Connection (POE) VIDEO SD MEMORY Minumum 15W required for POE DO NOT REMOVE - CIF MEMORY SD Card Warning! DO NOT POWER WITH 24V INPUT AND POE SIMULTANEOUSLY. REMOTE CONTROL POWER Turns display On/Off... -
Page 8: Display Menu
Display Menu... -
Page 9: Osd Menu Overview
OSD Menu Using the remote control, or button pad located on the back of the device, press the Menu button. The following selections will appear. Video Display Audio System Settings Video: Adjust picture settings such as Contrast, Brightness, Saturation, Tint, Sharpness, Color Temperature, and select from video image mode presets. -
Page 10: Display Menu
Display • Aspect Ratio: Select the display aspect ratio (Full Screen, Cinema Scope, 4:3, Pillar Box Expand, 1:1). Full Screen is the default setting and will display the image without stretching. Use Cinema Scope for a more natural image and to stretch SD Card content to fill the screen. •... -
Page 11: Audio Menu
Motion VOV SD- Displays SD Card content full screen. Live camera image will display in VOV window when motion is sensed. LOGO LOGO From the sub-menu, select the number of seconds VOV window will remain on screen after motion is sensed, as well as the VOV window size and position. -
Page 12: System Settings
System Settings • Language: Display the OSD menu in English or Spanish. Note: Changing the Language does not change the flashing on-screen message. This must be changed in the Special Control > Message setting. • OSD Timer: Set the time in seconds before the OSD menu disappears. Turn timer OFF to close the OSD menu upon exit button press only. -
Page 13: Sd Card
Upload SD Card Content The PVM is capable of displaying JPEG images or AVI video files from an SD Card. Before loading files onto the SD Card, you MUST format the card to FAT-32. Failure to format the SD Card may result in a black screen showing instead of the desired image or video. The preferred JPEG image size is 1024 x 768. -
Page 14: Camera Software
Camera Software... -
Page 15: Ip Installer - Windows 13-14
IP Installer Software - Windows PC To complete the installation of your IP camera based PVM, follow the procedure below: 1. Install Software After the PVM has been installed, download the installation software by inserting the CD-ROM into a Windows PC. The setup page will show up automatically. - Page 16 When accessing the IP Camera for the first time, a yellow information bar appears below the address bar: This website wants to install the following add-on: ‘AxvideoView.cab’ and/or ‘AxPlayer.cab’ from ‘Clinton Electronics’. Click Install. 5. Allow IP Camera Pop-Up’s Depending on your computer’s Privacy settings, an information bar may appear alerting you about blocking a pop-up.
-
Page 17: Web Viewer - Mac Osx
Web Viewer - MAC OSX + Safari 1. Configure Bonjour in Safari Open the SAFARI browser. For the Web Viewer to function properly, Bonjour must be configured. The Bonjuor function does not work in Google Chrome or Firefox. 2. Configure Bonjour Open Preferences in the Safari Menu bar. - Page 18 3. Live Viewing After successfully logging into the camera, the live image from the camera displays in the center of the screen. Options are limited on the MAC (Safari) web viewer compared to the PC (Internet Explorer) version. SETTINGS HOME CLIENT SETTING •...
- Page 19 6701 Clinton Road Loves Park, IL 61111 | 800.447.3306 (Sales) | 800.549.6393 (Support) | www. clintonelectronics.com...
