- Page 1 Public View Monitor Manual A-SERIES v07.10.15 6701 Clinton Road Loves Park, IL 61111 | 800.447.3306 (Sales) | 800.549.6393 (Support) | www. clintonelectronics.com...
-
Page 2: Table Of Contents
Warning & Compliance Important Safeguards Hardware Overview PVM Exterior Back Panel Connections Remote & Button Pad SD-Card Display Menu OSD Menu Overview Video Menu 9-10 Display Menu Audio & System Settings Camera - Quick Setup Mini CD Method - IP Utility 13-14 Software Download Method - IP Utility Camera Access &... -
Page 3: Warning & Compliance
The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) -
Page 4: Important Safeguards
1. Read Instructions If the equipment does not operate normally by All the safety and operating instructions should be following the operating instructions, adjust only read before the appliance is operated. those controls that are covered by the operating instructions as an improper adjustment of other 2. -
Page 5: Hardware Overview
Hardware Overview... -
Page 6: Pvm Exterior
FRONT IP Camera Lens Remote Receiver LED Flasher VESA 75 x 75 BACK VESA 100 x 100 VESA 100 x 200 (27” & 32” Only) VESA 100 x 100 POWER AUTO DOWN MENU Power Button Auto Button Up Button Down Button Menu Button... -
Page 7: Back Panel Connections
DO NOT REMOVE - CIF MEMORY Service Port SD Card (Not User Serviceable) VIDEO SD MEMORY DO NOT REMOVE - CIF MEMORY Note: A-Series PVMs which have a manufactured date prior to May 19th, 2015 do not have SD-Card or BNC Output features. -
Page 8: Remote & Button Pad
BUTTON PAD AUTO MENU Closes the OSD Menu or Shows the OSD Menu returns to previous menu POWER AUTO DOWN MENU POWER ARROW BUTTONS Turns display On/Off Navigates the OSD Menu REMOTE CONTROL SOURCE POWER Switches between Turns display On/Off video inputs MUTE Turns audio On/Off... - Page 9 Upload SD Card Content The PVM is capable of displaying JPEG images or AVI video files from an SD Card. Note: A-Series PVMs manufactured prior to May 19th, 2015 do not have SD-Card or BNC Output features. The preferred JPEG image size is 1024 x 768. Load files directly onto the card. Do not place files into folders.
-
Page 10: Display Menu
Display Menu... -
Page 11: Osd Menu Overview
OSD Menu Using the remote control, or button pad located on the back of the device, press the Menu button. The following selections will appear. Video Display Audio System Settings Video: Adjust picture settings such as contrast, brightness, color, tint, sharpness, color temperature, and select from video image presets. -
Page 12: Display Menu
Video continued... • Color: (21” model only) Adjust to achieve a realistic image of the items within the viewing area. • Saturation: (27” & 32” models only) Adjust to achieve a life-like separation between colors. • Tint: Adjust if the image has bluish or reddish tint to the white portions of the image. •... -
Page 13: Audio & System Settings
• Output: Choose the audio output signal (SD-Audio, Chime). Note: Chime feature not available or disabled on A-Series devices. System Settings • Language: Display the OSD menu in the following languages: English, Korean, French, Dutch, Italian (English and Spanish only on 27”... -
Page 14: Camera - Quick Setup
Camera | Quick Setup... -
Page 15: Mini Cd Method - Ip Utility
Camera Overview The A-Series PVMs feature an Axis M1025 camera built-in. This IP camera is POE capable (48V POE). When using POE, the camera will continue to be powered, and output video even if the main 24VDC (or 110VAC) power is disconnected from the PVM. -
Page 16: Software Download Method - Ip Utility
Login to camera Use the default Username and password below to login to your camera. If the default settings do not work, the camera has probably been set up already. Locate the correct username and password, or refer to the next page for resetting the camera. Default Username: root Default Password: pass Note: If you see the message above, follow this procedure: Run Internet Explorer... -
Page 17: Camera Access & Setting Reset
Camera Access It may be necessary to access the Axis camera located inside the PVM. To access, remove the 2 door screws located on the bottom of the PVM. Keep these screws in a safe place to close the access door when finished. CONTROL BUTTON POWER AUTO... - Page 18 6701 Clinton Road Loves Park, IL 61111 | 800.447.3306 (Sales) | 800.549.6393 (Support) | www. clintonelectronics.com...
