AVR
ATmegaICE User Guide
ATmegaPOD is the pod card used for the microcontrollers ATmega103/603.
The pod contains several jumpers which must be set to achieve the desired operation.
The jumpers involved in the configuration are indicated in Figure 3-1.
Figure 3-1. Pod Jumper Placements
J500
EXT. POWER
J110/J111
IN-SYSTEM
J200/J201/J202
TARGET VOLTAGE
CONNECTORS
J112/J113
IN-SYSTEM CONNECTORS
Section 3
ATmegaPOD
J351/J350
TCLK SRC.
J354/J352
TCLK FREQ.
J300
EXT. CLOCK
3-1
