AVR ATmegaICE Connector Description
8.2 Logic Analyzer 2
Connector
Description
8.3 AUX Connector
Description
8-2
Figure 8-2. Logic Analyzer 2 Connector
The connector marked "Logic Analyzer 2" on the back panel of the AVR ICE unit has the
following pin-out with signals from the instruction data bus.
Table 8-2. Logic Analyzer Connector 2
SIGNAL
AVRCLK
Low
D14
D12
D10
D8
D6
D4
D2
D0
Figure 8-3. AUX Connector
The connector marked "AUX" on the back panel of the AVR ICE unit is used for external
triggers and has the following pinout:
Table 8-3. AUX Connector
SIGNAL
GND
Input 0
Input 1
Input 2
Input 3
Input 4
GND
Logic Analyzer 2
Pin 1 Pin 2
Pin 3 Pin 4
Pin 5 Pin 6
Pin 7 Pin 8
Pin 9 Pin 10
Pin 11 Pin 12
Pin 13 Pin 14
Pin 15 Pin 16
Pin 17 Pin 18
Pin 19 Pin 20
AUX
Pin 1 Pin 2
Pin 3 Pin 4
Pin 5 Pin 6
Pin 7 Pin 8
Pin 9 Pin 10
Pin 11 Pin 12
Pin 13 Pin 14
SIGNAL
Low
D15
D13
D11
D9
D7
D5
D3
D1
GND
SIGNAL
GND
Output 0
Output 1
Output 2
Output 3
Output 4
GND
®
