Atmel AVR AT90S8515-4 Specification Sheet

Features
®
•
Utilizes the AVR RISC Architecture
•
AVR – High-performance and Low-power RISC Architecture
– 118 Powerful Instructions – Most Single Clock Cycle Execution
– 32 x 8 General-purpose Working Registers
– Up to 8 MIPS Throughput at 8 MHz
•
Data and Nonvolatile Program Memory
– 8K Bytes of In-System Programmable Flash
Endurance: 1,000 Write/Erase Cycles
– 512 Bytes of SRAM
– 512 Bytes of In-System Programmable EEPROM
Endurance: 100,000 Write/Erase Cycles
– Programming Lock for Flash Program and EEPROM Data Security
•
Peripheral Features
– One 8-bit Timer/Counter with Separate Prescaler
– One 16-bit Timer/Counter with Separate Prescaler
Compare, Capture Modes and Dual 8-, 9-, or 10-bit PWM
– On-chip Analog Comparator
– Programmable Watchdog Timer with On-chip Oscillator
– Programmable Serial UART
– Master/Slave SPI Serial Interface
•
Special Microcontroller Features
– Low-power Idle and Power-down Modes
– External and Internal Interrupt Sources
•
Specifications
– Low-power, High-speed CMOS Process Technology
– Fully Static Operation
•
Power Consumption at 4 MHz, 3V, 25°C
– Active: 3.0 mA
– Idle Mode: 1.0 mA
– Power-down Mode: <1 µA
•
I/O and Packages
– 32 Programmable I/O Lines
– 40-lead PDIP, 44-lead PLCC and TQFP
•
Operating Voltages
– 2.7 - 6.0V for AT90S8515-4
– 4.0 - 6.0V for AT90S8515-8
•
Speed Grades
– 0 - 4 MHz for AT90S8515-4
– 0 - 8 MHz for AT90S8515-8
8-bit
Microcontroller
with 8K Bytes
In-System
Programmable
Flash
AT90S8515
Summary
Note: This is a summary document. A complete document is
available on our web site at www.atmel.com.
Rev. 0841GS–09/01
