Technical Data - AAT c-max Translation Of The Original User Manual

2.3

Technical data

measurements
weight
total weight approved
max. weight of the person
climbing speed
range with one charge of the batteries
on average load of 75 kg
range with one charge of the batteries
on maximum load
maximum height of step
batteries
direct current motor
operating force UP/DOWN-switch
noise level
storing/operating temperature,device
storing/operating temperature,batteries
vibrations
height = min. 1090 mm - max. 1440 mm
width without arm rests = 440 mm
width with arm rests attached = 485 mm
depth with the foot rest folded in = 730 mm
depth with the foot rest folded out = 915 mm
climbing frame = 18,1 kg, C part plus seat = 5,5 kg, back rest = 4,5 kg,
both arm rests = 1,2 kg, battery pack = 4,1 kg, charger = 0,3 kg
total weight = 33,7 kg
190 kg
160 kg
8 - 23 steps / minute, continually adjustable
ca. 25 levels (equates 375 steps)
ca. 7 levels (equates 105 steps)
21 cm
2 x 12 V / 5 Ah sealed lead acid
24 V / 275 W
3-8 N
the device's A weighted noise level lies typically below 70 dB (A)
0° C up to + 60° C / - 30° C up to + 50° C
0° C up to + 60° C / - 30° C up to + 50° C
the weighted RMS value of acceleration the upper body is exposed to
lies typically below 2.5 m/s²
8
c-max
160 kg
