Technical Data - AAT c-max+ Translation Of The Original User Manual

Technology
Measurements
Weight
Total weight approved
Max. weight of the person
Climbing speed
Range with one charge of the batteries on
average load of 150 kg
Range with one charge of the batteries on
maximum load
Max. height of step
Min. depth of the step's surface
Necessary step width
(straight stairs)
Min. platform size
(U-shaped stairs)
14
c-max
+
Height = min. 1490 - max. 1837 mm
Width = 527 mm
Depth (with extended foot rest) =
1186 mm
Depth (with folded foot rest) =
1030 mm
Climbing unit = 50.2 kg
Seat unit = 19.8 kg
Handles = 4.8 kg
Battery pack = 4.5 kg
Charger = 0.2 kg
Total weight = 79.5 kg
380 kg
300 kg
approx. 3 - 8 steps / minute
approx. 20 levels
(equates 300 steps)
approx. 9 levels
(equates 135 steps)
210 mm
140 mm
Width c-max + 100 mm
+
Depends on the attendant's height
GB

2.2 Technical data
