Parts List - Linear DC2048A Demo Manual

parts list

ITEM QTY REFERENCE
Required Circuit Components
1 1 BAT1
2 1 BTH1
3 1 C1
4 1 C2
5 2 C7, C8
6 2 C3, C6
7 1 C11
8 1 C4
9 1 C5
10 2 C9, C10
11 1 L1
12 1 L2
13 3 R2, R4, R6
14 0 R3, R5, R7
15 2 R8, R9
16 1 U1
Additional Demo Board Circuit Components
1 0 BTH2
2 1 R1
3 3 U2, U3, U4
Hardware: For Demo Board Only
1 15 E1-E8, E12-E19
2 3 E9-E11
3 1 J1
4 10 JP1-JP10
5 1 JP11
6 11 JP1-JP11
PART DESCRIPTION
CR2032 COIN LI-ION BATTERY
SMT, CR2032 BATTERY HOLDER
SUPERCAP, 90mF, 5.5V, 20mm × 15mm
CAP, CHIP, X5R, 100µF, 20%, 10V, 1210
CAP, CHIP, X5R, 22µF, 20%, 6.3V, 1206
CAP, CHIP, X5R, 1µF, 10%, 6.3V, 0402
CAP, CHIP, X5R, 10µF, 10%, 6.3V, 0805
CAP, CHIP, X5R, 22µF, 10%, 25V, 1210
CAP, CHIP, X5R, 4.7µF, 10%, 6.3V, 0603
CAP, CHIP, X5R, 0.1µF, 10%, 10V, 0402
INDUCTOR, 22µH, 0.35A, 1.9Ω, 4.1mm × 4.1mm
INDUCTOR, 22µH, 0.75A, 0.19Ω, 4.8mm × 4.8mm
RES, CHIP, 0Ω, 0603
RES, CHIP, 0Ω, 0603
RES, CHIP, 7.5k, 1/16W,1%,0402
ENERGY HARVESTING DC/DC WITH BATTERY B
SMT, CR2477 BATTERY HOLDER
RES,CHIP, 1k, 1/16W, 1%, 0402
IC, UHS UNIV. CONFIG. TWO-INPUT GATES, SC
TURRET, 0.09 DIA
TURRET, 0.061 DIA
HEADER, 12 PIN, DUST HEADER 2×6
HEADER, 3 PINS, 2mm
HEADER, 4 PINS, 2mm
SHUNT 2MM
DEMO MANUAL DC2048A
MANUFACTURER/PART NUMBER
DURACELL, CR2032
MPD INC, BU2032SM-HD-GCT-ND
CAP-XX, HZ202F
TAIYO YUDEN, LMK325ABJ107MM
TAIYO YUDEN, JMK316BJ226ML-T
TDK, C1005X5R0J105KT
AVX, 08056D106KAT2A
AVX, 12103D226KAT1A
TDK, C1608X5R0J475KT
TDK, C1005X5R1A104K
COILCRAFT, LPS4018-223MLC
COILCRAFT, LPS5030-223MLC
VISHAY, CRCW06030000FKED
VISHAY, CRCW06030000FKED
VISHAY, CRCW04027K50FKED
LINEAR TECH, LTC3330EUH
RENATA, SMTU2477-1
VISHAY, CRCW04021K00FKED
FAIRCHILD, NC7SZ58P6X
MILL-MAX, 2501-2
MILL-MAX, 2308-2
SAMTEC, SMH-106-02-L-D-05
SAMTEC, TMM-103-02-L-S
SAMTEC, TMM-104-02-L-S
SAMTEC, 2SN-BK-G
dc2048af
13
