DEMO MANUAL
DC2631A-A/DC2631A-B

PARTS LIST

DEMO CIRCUIT 2631A-A
ITEM QTY REFERENCE
Required Circuit Component DC2631A-A
1 14 C1, C2, C5, C6, C18, C19, C24, C25,
C28, C29, C32, C33, C36, C37
2 18 C3, C4, C8, C9, C10, C11, C12, C13,
C14, C15, C16, C17, C20, C21, C22,
C23, C34, C35
3 2 C30, C31
4 2 C46, C47
5 2 C48, C50
6 2 C49, C51
7 1 C7
8 12 CIN1, CIN2, CIN3, CIN4, CIN5, CIN6,
CIN7, CIN8, CIN9, CIN10, CIN11, CIN12
9 2 CIN13, CIN14
10 1 CITH1
11 1 CITH2
12 2 CITHP1, CITHP2
13 6 COUT1, COUT3, COUT5, COUT7,
COUT9, COUT11
14 18 COUT13, COUT14, COUT15, COUT16,
COUT17, COUT18, COUT19, COUT20,
COUT21, COUT22, COUT23, COUT24,
COUT25, COUT26, COUT27, COUT28,
COUT29, COUT30
15 6 L1, L2, L3, L4, L5, L6
16 6 R19, R23, R38, R41, R66, R69
17 6 R20, R21, R22, R24, R25, R26
18 24 R3, R5, R7, R8, R11, R12, R14, R16,
R17, R18, R27, R29, R39, R40, R46,
R49, R67, R68, R105, R110, R113,
R116, R119, R122
19 4 R33, R34, R54, R55
8
PART DESCRIPTION
CAP ., 2.2µF, X5R, 16V, 10%, 0603
CAP ., 0.22µF, X5R, 25V, 10%, 0603
CAP ., 0.1µF, X7R, 16V, 10%, 0603
CAP ., 1µF, X7R, 50V, 10%, 0805
RES., AEC-Q200, 100Ω, 1%, 1/8W, 0805
CAP ., 47µF, X5R, 6.3V, 20%, 0805
CAP ., 1µF, X5R, 25V, 20%, 0603
CAP ., 22µF, X5R, 25V, 10%, 1210
CAP ., 180µF, 30mΩ, ALUM. POLYMER, 16V,
20%, SMD"
CAP ., 3300pF, X7R, 50V, 10%, 0603
CAP ., 2200pF, C0G, 50V, 5%, 0603
CAP ., 150pF, NP0, 50V, 5%, 0603
CAP ., 220µF, X5R, 4V, 20%, 1206, NO SUBS.
ALLOWED
CAP ., 330µF, 9mΩ, ALUM. POLYMER, 2.5V,
20%, 7343, 6.3A"
INDUCTOR, 0.25µH, 0.32mΩ
RES., 715Ω, 1%, 1/10W, 0603
RES SMD 2.32KΩ, 1%, 1/10W, 0603
RES., AEC-Q200, 0Ω, 1/10W, 0603
RES., COPPER, 0mΩ, JUMPER, 2010
MANUFACTURER/PART NUMBER
KEMET, C0603C225K4PAC7867
KEMET, C0603C225K4PACTU
AVX, 06033D224KAT2A
MURATA, GRM188R61E224KA88D
NIC, NMC0603X5R224K25TRPF
TAIYO YUDEN, TMK107BJ224KA-T
AVX, 0603YC104JAT4A
AVX, 08055C105KAT2A
TAIYO YUDEN, UMK212B7105KG-T
TDK, C2012X7R1H105K125AB
VISHAY, CRCW0805100RFKEA
TAIYO YUDEN, JMK212BBJ476MG-T
TDK, C2012X5R0J476M125AC
TAIYO YUDEN, JMK212BJ476MG-T
AVX, 06033D105MAT2A
TAIYO YUDEN, TMK107BJ105MA-T
TDK, C1608X5R1E105M080AC
MURATA, GRM32ER61E226KE15L
TAIYO YUDEN, TMK325BJ226KM-P
AVX, 12103D226KAT2A
TAIYO YUDEN, TMK325BJ226KM-T
PANASONIC, 16SVP180MX
AVX, 06035C332KAT2A
MURATA, GRM188R71H332KA01D
NIC, NMC0603X7R332K50TRPF
MURATA, GCM1885C1H222JA16D
AVX, 06035A151JAT2A
MURATA, GRM31CR60G227ME11L
PANASONIC, EEFSX0E331ER
WURTH ELEKTRONIK, 744301025
NIC, NRC06F7150TRF
SAMSUNG, RC1608F7150CS
YAGEO, RC0603FR-07715RL
VISHAY, CRCW06032K32FKEA
VISHAY, CRCW06030000Z0EA
NIC, NRC06ZOTRF
TEPRO OF FLORIDA, RN6083
