DEMO MANUAL SCP-LT1962-EVALZ

PARTS LIST

ITEM

QTY

REFERENCE

1

1

PCB

2

1

C1

3

1

C2

4

1

C3

5

1

INPUT

6

1

OUTPUT

7

1

P1

8

1

R1

9

1

R2

10

1

R3

11

1

R4

12

1

R5

13

1

U1

Note 1. These items are not stuffed (DNI).

4

PART DESCRIPTION

PCB

CAP 2.2uF 25V CER X5R 0603

CAP CER 0.1uF 50V CER X5R 0402

CAP CER 10uF 50V X5R 1206

CONN MALE 3POS 2.54MM PITCH R/A

CONN FEMALE 3POS 2.54MM PITCH R/A

CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY STRAIGHT

2MM PITCH (Note 1)

RES 422k 1% THICK FILM 0805

RES 100k 1% THICK FILM 0805

RES THICK FILM 0805 (Note 1)

RES THICK FILM 0805 (Note 1)

RES 249k 1% THICK FILM 0805

IC-LIN LOW NOISE, MICROPOWER LDO REGULATOR

MANUFACTURER/PART NUMBER

ANALOG DEVICES 08_051164b

MURATA GRM188R61E225KA12D

YAGEO CC0402KRX5R9BB104

SAMSUNG CL31A106MBHNNNE

SULLINS PBC03SBAN

SULLINS PPPC031LGBN-RC

MOLEX 53253-0370

YAGEO RC0805FR-07422KL

PANASONIC ERJ-6ENF1003V

N/A

N/A

VISHAY CRCW0805249KFKECC

ANALOG DEVICES LT1962EMS8#PBF
