DEMO MANUAL SCP-ADP7182-EVALZ

PARTS LIST

ITEM

QTY

REFERENCE

1

1

PCB

2

2

C1, C2

3

1

C4

4

1

INPUT

5

1

OUTPUT

6

1

P1

7

1

R1

8

2

R2, RNR

9

1

R4

10

2

R5, R6

11

1

U1

Note 1. These items are not stuffed (DNI).

4

PART DESCRIPTION

PCB

CAP 4.7UF 50V CER X7R 1206

CAP 0.1uF 50V CER X7R 0805

CONN-PCB MALE 3POS 2.54MM PITCH R/A

CONN FEMALE 3POS 2.54MM PITCH R/A

CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY STRAIGHT

2MM PITCH (Note 1)

RES 196k 1% THICK FILM 0805

RES 115k 1% THICK FILM 0805

RES 1.00M 1% THICK FILM 0805

RES THICK FILM 0805 (Note 1)

IC-ADI LOW NOISE, CMOS LDO LINEAR REGULATOR

MANUFACTURER/PART NUMBER

ANALOG DEVICES 08_051389b

SAMSUNG CL31B475KBHNNNE

AVX CORPORATION 08055C104JAT2A

SULLINS PBC03SBAN

SULLINS PPPC031LGBN-RC

MOLEX 53253-0370

YAGEO RC0805FR-07196KL

VISHAY CRCW0805115KFKEA

YAGEO RC0805JR-071ML

N/A

ANALOG DEVICES ADP7142ACPZN-R7

Rev. 0
