• Keep away from the hinges and any moving mechanical parts • Stay out other use is therefore improper and dangerous. CAME Cancelli Automatici S.p.A. of the operating range of the operator while it is moving • Do not oppose is not liable for any damage due to improper, erroneous and unreasonable use the movement of the operator as this may result in danger •...
This symbol tells you what to say to the end users. ☞ REGULATORY REFERENCES Came Cancelli Automatici is a company with an ISO 9001-certified company quality management system and an ISO 14001-certified environmental management system. The product complies with the regulations referred to in the declaration of conformity.
Description of the components 1. Gearmotor 2. Transmission lever 3. Gearmotor arm 4. Adjusting screw for closing limit switch UNI 5739 M12x120 5. Couple release lever 6. Gate mounting bracket 7. Adjusting screw for opening limit switch UNI 5739 M12x70 8.
Dimensions (mm) GENERAL INSTALLATION INSTRUCTIONS Installation must be carried out by qualified and experienced personnel in compliance with applicable regulations. ⚠ Preliminary checks Before installing the operator: ⚠ • Provide a suitable single-pole disconnection device, with a maximum of 3 mm between the contacts, to disconnect the power supply; •...
INSTALLATION The following illustrations are only examples, given that the space for securing the operator and accessories varies depending on the overall dimensions. ⚠ The installation technician is responsible for choosing the most suitable solution. the figures below illustrate the installation of the right-hand foundation box. Laying the corrugated pipes and inspection chambers Make the hole for the box.
Page 7
Drawing view: RH side from the inside. Lubricate the pivoting point of the foundation case, the latch and the pin of the gate bracket. Install the gate leaf, inserting the upper hinge. Fix or carefully weld the leaf to the fixing bracket to the gate. Check that the leaf opens and closes without difficulty.
Securing the gearmotor Insert the adjusting screw in the gearmotor arm. The sense in which the screw is fitted depends on the position of the automation. LEFT SIDE RIGHT SIDE VIEWED FROM INSIDE Open the door to facilitate the placement of the gearmotor in the foundation case and its anchoring. Secure the gearmotor using the nuts supplied.
- loosen the screw (1) until it makes contact with the transmission arm (2); - tighten the nut (3) to lock the position of the screw. ELECTRICAL CONNECTIONS For electrical connection operations, see the control panel technical documentations. Gearmotor Control panel FROG-PM4 ZM3EP FROG-PM6 ZM3EP FINAL OPERATIONS Securing the cover...
Manual release of the leaf Insert the key/lever into the release lock and turn it counter-clockwise. Open the leaf until end run To relock the door, return it to its closed position. 7 Maintenance Periodic maintenance Before doing any maintenance, cut off the power supply, to prevent any hazardous situations caused by accidentally activating the operator. ☞ ...
CAME S.p.A. employs a UNI EN ISO 14001 certified and compliant environmental protection system at its plants, to ensure that environmental safeguarding. We ask you to keep protecting the environment, as CAME deems it to be one of the fundamental points of its market operations strategies, by simply following these brief guidelines when disposing: DISPOSING THE PACKING MATERIALS The packing components (cardboard, plastic, etc.) are solid urban waste and may be disposed of without any particular difficulty, by...
Page 12
HR • Za sve dodatne informacije o poduzeću, proizvodima i tehničkoj podršci: UK • Для отримання будь-якої іншої інформації про компанію, продукцію та технічну підтримку: www. came.com www. came.com CAME Cancelli Automatici S.p.a. CAME Cancelli Automatici S.p.a. Via Martiri Della Libertà, 15 31030 Dosson Di Casier...
