Loosen the two pre-mounted screws in the codec
8
power supply bracket above the codec. Slide the
power supply into the bracket and tighten the
two screws.
Adjust the handles by loosening the two screws
9
on each bar (four screws per side). Extend the
handle at or beyond the display by 1-2". Replace
the screws and tighten. Use the same hole in the
series of holes on both sides. These handles will be
used to move the cart.
Polycom® RealPresence® EduCart 500 Setup Sheet
TM
Place the speaker brackets grill forward and
10
directly under the display on the outside of the
poles. Attach them with U-shaped brackets using
nuts and a 7/16" wrench.
Attach the supplied bracket to the speaker. The
11
bracket can be spread open to fit over the speaker.
