Polycom RealPresence EduCart 500 Setup Sheet page 2

Place the base on the floor and lock the wheels.
1
Insert each pole into the base with the threaded
inserts lined up with the holes at the rear of the
base. Loosely insert two 3/8" bolts with flat washers
on the back side and one in the bottom of each pole.
Tighten with a 9/16" wrench.
Remove the basket and basket bracket from the
2
H frame by removing the two screws circled in
red.
Polycom® RealPresence® EduCart 500 Setup Sheet
TM
Loosen and rotate the camera bracket and slide it
3
out to avoid hitting the display during installation.
The camera bracket is rotated for packaging and
must be rotated to the correct position.
Attach the codec to the H frame with the
4
M3 x 8 Phillips pan head screws.
2
