3. Speci cation
3-1 Receiver// UR-816D (DB)
Frequency Preparation...
Carrier Frequency Range
S/N Ratio....................
T.H.D.........................
Display.......................
Display Contents...........
Controls......................
Audio Output Level.......
AF Output Impedance....
Squelch.......................
Operation Voltage.........
Output Connector..........
Dimension(m/m)...........
3-2 Miniature Transmitter// UT-16GT/UT-16GTP
Frequency Preparation.....
Carrier Frequency Range..
RF Outputs....................
Stability........................
Frequency Deviation........
LED Display...................
Controls........................
Spurious Emissions..........
Audio Frequency Response
Ba ery.........................
PLL Synthesized Control
502~960 MHz
> 105dB
<0.6%@1KHz
LED
Antenna A/B, RF/AF Status
Power On/O , Channel Selecting, Audio Level
-12dB
600
Pilot Tone, Noise and Mute
12-18 VDC, 200mA
1 Balanced XLR socket
1 Unbalanced Ø6.3mm phone jack
816D
210mm (W)* 40mm (H)* 171mm (D)
816DB 210mm (W)* 40mm (H)* 181mm (D)
PLL Synthesized Control
502~960 MHz
Maximum 10mW
±10KHz
±48KHz
Power On/O , Low ba ery, Mute
Power On/O , AF Level, Channel Selecting, Mute
<-50 dBC
40~18,000 Hz
LR03, AAA 1.5V*1
02
