Your new VHX-35F kit includes:
Ford Adapter
Universal Sender Pack
Switch Assembly
Installation
1. Use the provided template to mark out the opening needed to fit the VHX display. Ensure there is
adequate clearance behind the desired mounting location. The display unit needs approximately 2.5"
of depth behind the dash. The overall bezel size is shown below.
VHX-35F
Dakota Digital VHX Instrument Installation
For 1935-36 Ford Car
Installation Manuals
and Cutout Template
CAT5 Cable
VHX Display
(2x) U-Brackets
(4x) Thumb Nuts
Control Box
Manual # 650441A
Advertisement
Table of Contents
Related Manuals for Dakota Digital VHX-35F
Summary of Contents for Dakota Digital VHX-35F
- Page 1 VHX-35F Dakota Digital VHX Instrument Installation For 1935-36 Ford Car Your new VHX-35F kit includes: VHX Display Ford Adapter Universal Sender Pack Installation Manuals and Cutout Template (2x) U-Brackets (4x) Thumb Nuts Switch Assembly CAT5 Cable Control Box Installation 1. Use the provided template to mark out the opening needed to fit the VHX display. Ensure there is adequate clearance behind the desired mounting location.
- Page 2 2. With the appropriate opening cut, place the VHX display into the dash and attach the two (2) U-brackets to the back of the display using the provided thumb nuts. 3. Attach the provided CAT5 cable to the back of the VHX display and carefully route the other end to the control box mounting location.
