6.6 USB Flash memory (Optional)
A USB drive can be used as a method of storing a report of the
cycle. To do so, insert the USB drive to the slot on the right side of
the instrument.
The information will automatically output directly to the USB
after the cycle has completed.
The name of the file is determined by the serial number of
the machine and the cycle number.
For example :
The serial number is E00001 The cycle number is 00012
The file name in the USB stick is 0 0 1200 txt
The first two numbers represent machine number
The middle four numbers represent cycle number
The last two numbers represent error code
: ; :
00 no error 01 error E01
6.7 Retrieve information from a prior cycle
Press PROGRAM repeatidly until you enter
the prior program storage screen.
This will show the cycle No.
Press the TEMP button to toggle between
different cycles.
To print or send details to the USB drive,
press the START button. The most recent
20 records are stored.
When vieing printed data records, refer to the diagram below:
P
t
7
t t
T
1 3 5
t t t
1
4
2 6
1 3
.
1 0 . .
.
.
.
t
s
t
8
t
2
Instructions manual
=========================
Program:
Temperature: 274 F
Pressure:30.5 psi
Dry Time: 03Min
Ster Time: 4.0Min
-------------------------------------
time
Start 15:24:20 107.6 F
T1: 15:32:11 158.0 F 07.71psi
T2: 15:36:08 167.5 F 01.42psi
T3: 15:39:21 194.5 F 07.30psi
.
T4: 15:44:32 094.3 F 01.39psi
T5: 15:47:12 201.7 F 14.91psi
T6: 16:00:11 230.3 F 01.35psi
TS:
Max.Temperature:275.2 F
Min.Temperature:274.1 F
Max.Pressure:33.42psi
Min.Pressure:30.88psi
T7: 16:04:02 275.0
T8: 16:06:32 274.6 F 31.05psi
End 16:14:12 172.8 F
--------------------------------------
Cycle No: 0005
Ster Value: Success
Date: 2011-01-18
SN:E00001
Operator:
=======================
Instructions manual
=========================
WRAPPED Program:
Temperature: 274 F
Pressure:30.5 psi
Dry Time: 03Min
Ster Time: 4.0Min
-------------------------------------
temp. pressure time
Start 17:34:20 179.6 F
T1: 17:42:11 194.0 F 07.57psi
T2: 17:46:08 185.5 F 01.41psi
T3: 17:49:21 226.9 F 07.75psi
T4: 17:54:32 212.5 F 01.39psi
T5: 00:00:00 000.0 F 000.0psi
T6: 00:00:00 000.0 F 000.0psi
274.6 F 32.14psi TS:
MAX.Temperature:000.0 F
MIN.Temperature:000.0 F
MAX.Pressure:000.0psi
MIN.Pressure:000.0psi
F 32.42psi T7: 00:00:00 000.0 F 000.0psi
T8: 00:00:00 000.0 F 000.0psi
End 17:54:42 212.4 F 01.46psi
--------------------------------------
Cycle No: 0007
Ster Value: Failure E01
Date: 2011-01-18
SN:E00001
Operator:
=======================
WRAPPED
temp. pressure
000.0 F 000.0psi
