- Page 1 Device manual PKV 50-XXX Target System for Ethernet-/Fieldbus Applications Hilscher Gesellschaft für Systemautomation mbH Rheinstraße 15 D-65795 Hattersheim Germany Tel. +49 (6190) 9907 - 0 Fax. +49 (6190) 9907 - 50 Sales: +49 (6190) 9907 - 0 Hotline and Support: +49 (6190) 9907 - 99 Sales email: sales@hilscher.com...
-
Page 2: List Of Revisions
2 26.07.02 revised Although this appliance has been developed with great care and intensively tested, Hilscher Gesellschaft für Systemautomation mbH cannot guarantee the suitability of this appliance for any purpose not confir- med by us in writing. Guarantee claims shall be limited to the right to require rectification. Liability for any damages which may have arisen from the use of this appliance or its documentation shall be limited to cases of intent. -
Page 3: Table Of Contents
4.1 Technical Data ..................Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 4: Introduction
Configurator via the RS232C serial diagnostic interface or remotely via TCP/IP. The PKV 50 fieldbus Gateway is now offered for the most important fieldbus systems. Customer-specific solutions can be implemented by us or by the customer himself. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 5: Structure Of The Gateway
Wi ndows CE PC T a s k Fieldbus Interface Realtime OS Tasks for Fieldbus protocol Packet Driver Fieldbus Ethernet Physical Physical dependent 10/100BaseT Fieldbus Ethernet The Gateway in the ISO/OSI reference model Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 6: General Device Description
Besides this, a charging ca- pacitor is available that blocks the voltage dips that occur in the switching of fuses. The operational readiness and an error in the communication interface are dis- played by LEDs. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 7: Configuration Of The Gateway With The Sycon System Configurator
In order to ensure communication via TCP/IP, the TCP/IP protocol on the PC must be configured in such a way that a connection with the default IP address is possible (see user manual for Windows NT). Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 8: Loading Files Into The Gateway
Gateway. According to requirements, now mark the buttons Save persistent, Execute after download and Execute after PKV boot. Now activate the Down- load button and the software is transferred to the Gateway. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 9: Loading Files On To The Host Pc
The target place and target name can be entered now in the Destination (PC) field or selected via the ... button After activating the Upload button, the file is loaded onto the Host PC. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 10: Deleting Files
A list of files that are permanently stored in the User FLASH memory is displayed now. Now previously selected files can be deleted with the Delete button. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 11: Setting The Ip Address
For this purpose the Configuration > Start Application menu has to be selected. Now enter the name of the application into the field provided for this purpose and press the OK button. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 12: Connecting The Supply Voltage (X2)
3-pin COMBICON plug from the PHOENIX company (MSTB 2,5/3-ST-5,08). Connection Symbol Signal +24V +24V supply voltage Reference potential Equipment grounding conductor Connector pin assignment of the operating voltage connection X2 Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 13: Interfaces
TXDE+ Output TXDE- Input RXDE+ Input RXDE- Pin assignment of the Ethernet interface The Ethernet interface is carried out by means of an 8 pin RJ45 socket for a 10/100BaseT connection. Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 14: Fieldbus Interface (X6)
Data line high Output Input/ CANL Data line low Output DGND Data reference potential shield shield of bus cable Pin assignment of the PKV 50-COM and PKV 50-DNM at the plug X6 Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 15: Diagnostic Interface (X3)
15 meters. The wiring of the cable is given below. For better interfe- rence suppression, the cable shielding also on the side of the Host PC should be grounded over the plug housing. Connecting cable between Gateway and Host PC Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 16: Status Displays
Task 6 Task 7 with without without with without with with DBM- Error Error Error Error Error Error con- Error figured Display of the tasks that have indicated a parametrizing error Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 17: Mechanical Dimensions
50022). The mechanical dimensions and the allocation of the pins are shown in the following figures. Front view with pin arrangement on the Gateway 1 0 5 1 0 5 Side view of the Gateway for clipping on to a carrier rail Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN... -
Page 18: Appendix
250 mA at 24 V Operating temperature 0 °C - 50 °C Protection IP20 Dimensions (L x W x H) 105 x 44 x 105 mm Installation DIN rail EN 50022 Copyright * Hilscher Gesellschaft für Systemautomation mbH * De:PKV50#2EN...
