Instructions - Parts List
Parts
2:1 Ratio Standard Pump
360 psi (25 bar) Maximum Fluid Working Pressure
180 psi (12.5 bar) Maximum Air Input Pressure
55 GALLON (200 LITER) DRUM SIZE
Model 226040, Series G
Stainless Steel, PTFE, Packed
Brevet No. 86-07085
5 GALLON (19 LITER) PAIL SIZE
Model 223954, Series B
Stainless Steel, PTFE Packed
Table of Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pump Parts (Model 223954
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Read warnings and instructions.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 1970, Graco Inc. is registered to I.S. EN ISO 9001
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
2
2
4
7
8
10
11
12
14
16
18
19
20
22
22
Model 223954 Shown
0359
307026P
II 1/2 G T6
ITS03ATEX11227
Advertisement
Table of Contents
Related Manuals for Graco 226040
Summary of Contents for Graco 226040
-
Page 1: Table Of Contents
......Model 223954 Shown Read warnings and instructions. II 1/2 G T6 GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441 ITS03ATEX11227 0359 Copyright 1970, Graco Inc. is registered to I.S. EN ISO 9001... -
Page 2: Symbols
D This equipment is for professional use only. D Read all instruction manuals, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco distributor. D Do not alter or modify this equipment. Use only genuine Graco parts and accessories. - Page 3 WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and re- sult in a fire or explosion and serious injury. D Ground the equipment and the object being sprayed. Refer to Grounding the System on page 4. D If there is any static sparking or you feel an electric shock while using this equipment, stop spray- ing/dispensing immediately.
-
Page 4: Installation
Contact your Graco distributor for assis- tance in planning a system to suit your needs. 2. Always use Genuine Graco Parts and Accesso- ries. 3. Reference numbers and letters in parentheses refer to the callouts in the figures and the parts lists on pages 12 through 15. - Page 5 Installation Pump Air Regulator Air Line Lubricator Air Line Filter Bleed-Type Master Air Valve (required, for pump) Fluid Drain Valve (required) 3/8 npt(f) Fluid Return Inlet G Grounded Air Hose Grounded Fluid Hose Pump Fluid Inlet 1/4 npt(f) Pump Air Inlet Bung Locknut M 1/2 npt(f) Pump Fluid Outlet Ground Wire (required;...
- Page 6 Installation D An air line filter (C) removes harmful dirt and System Accessories moisture from the compressed air supply. Refer to Fig. 2 and the Accessories section. D A second bleed-type air valve (D) isolates the air NOTE: To ensure maximum pump performance, be line accessories for servicing.
-
Page 7: Operation
Operation Pressure Relief Procedure WARNING PRESSURIZED EQUIPMENT HAZARD The system pressure must be manually relieved to prevent the system from starting or spraying acci- dentally. To reduce the risk of an injury from acci- 03765 Fig. 4 dental spray from the gun, splashing fluid, or moving parts, follow the Pressure Relief Proce- Starting and Adjusting the Pump dure whenever you:... -
Page 8: Troubleshooting
Operation Corrosion Protection for Pump Lubrication If you are not using an accessory air line lubricator, CAUTION manually lubricate the motor daily. Disconnect the air regulator, place about 15 drops of light machine oil in Water, or even moist air, can cause your pump to the pump air inlet, reconnect the regulator and turn on corrode. - Page 9 NOTES: 307026...
-
Page 10: Pump Service (Model 226040)
Pump Service (Model 226040) BEFORE YOU START 7. On the upper connecting rod (120), install one cup packing (107**) with the lips facing up, the bearing 1. Have all the necessary repair parts on hand. (108**), and the second packing (107**) with the Recommended spare parts are marked with an lips facing down. -
Page 11: Pump Service (Model 223954)
Pump Service (Model 223954) BEFORE YOU START 4. Unscrew the piston valve housing (309) from the lower connecting rod (315). Unscrew the piston 1. Have all the necessary repair parts on hand. body (313) from the piston valve housing (309). Recommended spare parts are marked with an asterisk (for example, 313*). -
Page 12: Pump Parts (Model 226040)
Pump Parts Model 226040, Series G Packed Stainless Steel, PTFE 118** 134** LIPS FACE DOWN 107** LIPS FACE UP 108** 107** LIPS FACE DOWN GROOVES FACE UP TORQUE TO 20-25 ft-lb (27-34 N.m) 104** GROOVES FACE DOWN 111** LIPS FACE UP... - Page 13 Pump Parts Model 226040, Series G Packed Stainless Steel, PTFE Ref. PART Part No. Description Qty. DESCRIPTION 166564** . BEARING, connecting rod 204722 AIR MOTOR; 204725 . FRAME, displacement pump See 307851 for parts 204885 . ROD, upper connecting; 204724 DISPLACEMENT PUMP ASSY 32.84”...
-
Page 14: Pump Parts
Pump Parts Model 223954, Series B Packed Stainless Steel, PTFE 318** 334** LIPS FACE DOWN 307** LIPS FACE UP 308** 307** LIPS FACE DOWN GROOVES FACE UP TORQUE TO 20-25 ft-lb (27-34 N.m) 304** GROOVES FACE DOWN 311** LIPS FACE UP 312** 311** LIPS FACE... - Page 15 Pump Parts Model 223954, Series B Packed Stainless Steel, PTFE Ref. Ref. Part No. Description Qty. Part No. Description Qty. 166564** . BEARING, connecting rod; filled PTFE 223953 AIR MOTOR; 223956 . FRAME, displacement pump; See 307851 for parts stainless steel 223955 DISPLACEMENT PUMP ASSY 223957...
-
Page 16: Accessories
Accessories Must be purchased separately. AIR REGULATOR AND GAUGE 300 psi (21 bar) MAXIMUM WORKING PRESSURE GROUNDING CLAMP 103538 GROUND WIRE 208950 202156 0-200 psi (0-14 bar) Regulated Pressure Range; 25 ft (7.6 m) long, 3/8 npt(f) inlet and outlet. 12 gauge (1.5 mm@) FLUID DRAIN VALVE BLEED-TYPE MASTER AIR VALVE... - Page 17 Accessories FLUID FILTER 300 psi (21 bar) MAXIMUM WORKING PRESSURE For filtering paint in a circulating system. 6 gpm (22.7 liter/min) maximum volume. 3/4 npt(f) inlet and outlet. 01358 213057 30 mesh 213058 60 mesh MOUNTING BRACKET 203987 For mounting Model 223954 to a wall. 213059 100 mesh 0779 PTFE FLUID HOSE 204865...
-
Page 18: Dimensions
(Adjustable) 3/4 npt(f) FLUID INTAKE (MODEL 223954 ONLY) 01347 Pump No. Overall Length Pump Length Weight 226040 50.25 in 32.375-33.875 in. 17 lb (7.7 kg) (1276 mm) (822-860 mm) 223954 30.5 in. 13.70-14.10 in. 1.5 lb (5.2 kg) (775 mm) -
Page 19: Service Information
Pump Model 206780 is obsolete and is removed from the Old parts listed directly above them. the manual. Pump Model 226040 is advanced to Series G. Dis- Repair Kit 214730 is obsolete and is superseded by placement Pump Model 204724 is advanced to Series Repair Kit 224005. -
Page 20: Technical Data
Technical Data Category Data Maximum fluid working pressure 360 psi (25 bar) Air input pressure operating range 30-180 psi (2-12 bar) Pump cycles per 1 gallon (3.8 liters) 40 (50 for Model 223954) Maximum recommended pump speed for 100 cycles per min continuous operation Air consumption approx. - Page 21 NOTE: Pump may be operated continuously to shaded area KEY: Fluid Outlet Pressure - Black Curves (100 cpm). Area shown is for Model 226040 only. For Model Air Consumption - Gray Curves 223954, 100 cpm line is at 1.5 gpm.
-
Page 22: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
