- Page 1 OPTIMUM M A S C H I N E N - G E R M A N Y Operating Manual Version 1.0.1 Bench drilling machine Part no. 302 0160 Part no. 302 0160 Part no. 302 0150 Part no. 302 0155...
-
Page 2: Table Of Contents
OPTIMUM M A S C H I N E N - G E R M A N Y Safety Type plate ..............................3 Safety instructions (warning notes)......................4 Intended use .............................5 Reasonably foreseeable misuse.......................6 Possible dangers caused by the drilling machine..................6 Qualification of personnel .........................7 User positions ............................8... -
Page 3: Safety
Always keep this documentation close to the drilling machine. Type plate INFORMATION If you are unable to rectify an issue using these operating instructions, please contact us for advice: Optimum Maschinen Germany GmbH Dr. Robert-Pfleger-Str. 26 D-96103 Hallstadt, Germany Email: info@optimum-maschinen.de... -
Page 4: Safety Instructions (Warning Notes)
OPTIMUM M A S C H I N E N - G E R M A N Y Safety instructions (warning notes) 1.2.1 Classification of hazards We classify the safety warnings into different categories. The table below gives an overview of the classification of symbols (ideogram) and the warning signs for each specific danger and its (possible) consequences. -
Page 5: Intended Use
If the drilling machine is used in any way other than described above, modified without authori- zation of Optimum Maschinen Germany GmbH, then the geared drill is being used improperly. We will not be held liable for any damages resulting from any operation which is not in accord- ance with the intended use. -
Page 6: Reasonably Foreseeable Misuse
OPTIMUM M A S C H I N E N - G E R M A N Y Reasonably foreseeable misuse Any use other than that specified under "Intended use" or any use beyond that described will be deemed non-intended use and is not permissible. -
Page 7: Qualification Of Personnel
OPTIMUM M A S C H I N E N - G E R M A N Y In the event of improper use there may be a risk to personnel, there may be a risk to the machine and other material values, ... -
Page 8: User Positions
OPTIMUM M A S C H I N E N - G E R M A N Y User positions The operator position is in front of the drilling machine. Safety devices Use the drilling machine only with properly functioning safety devices. Stop the drilling machine immediately, if a safety device fails or is faulty or becomes ineffective. -
Page 9: Personal Protective Equipment
OPTIMUM M A S C H I N E N - G E R M A N Y 1.12 Personal protective equipment For some works you need personnel protective equipment as protective equipment. These are Safety helmet, protective glasses or face guard, ... -
Page 10: Disconnecting And Securing The Drilling Machine
OPTIMUM M A S C H I N E N - G E R M A N Y 1.15 Disconnecting and securing the drilling machine Switch off the drill with the main switch and lock it so it cannot be activated by unauthorised per- sonnel or switched on by accident. -
Page 11: Technical Specification
OPTIMUM M A S C H I N E N - G E R M A N Y Technical specification The following information represents the dimensions and indications of weight and the manu- facturer‘s approved machine data for following stated machines. -
Page 12: Dx13V Dimensions
OPTIMUM M A S C H I N E N - G E R M A N Y DX13V Dimensions Ø Schwerpunkt - Centre of gravity DX13V | DX15V Technical specification Page 12 Original operating instructions Version 1.0.1 dated 2016-04-25... -
Page 13: Dx15V Dimensions
OPTIMUM M A S C H I N E N - G E R M A N Y DX15V Dimensions Schwerpunkt - Centre of gravity Technical specification DX13V | DX15V Version 1.0.1 dated 2016-04-25 Original operating instructions Page 13... -
Page 14: Assembly
OPTIMUM M A S C H I N E N - G E R M A N Y Assembly Unpacking the machine Transport the drilling machine in its packing crate near its final installation location with a lift truck before unpacking it. If the packaging shows signs of possible transport damage, take the necessary precautions not to damage the machine when unpacking it. -
Page 15: Installation Site Requirements
OPTIMUM M A S C H I N E N - G E R M A N Y 2 x fastening bore Schwerpunkt / Centre of gravity Img.3-1: Example DX13V | DX15V with Machine Base 335 3000 Installation site requirements Organize the work area around the drill according to local safety regulations. -
Page 16: Cleaning Of The Machine
OPTIMUM M A S C H I N E N - G E R M A N Y Please observe the following points: The machine must only be installed and operated in a dry and well-ventilated place. Avoid places near machines generating chips or dust. -
Page 17: Operation
OPTIMUM M A S C H I N E N - G E R M A N Y Operation Control and indicating elements DX13V Pos. Designation Pos. Designation Control panel "Control panel“ on page EMERGENCY STOP push button Drilling lever... -
Page 18: Control And Indicating Elements Dx15V
OPTIMUM M A S C H I N E N - G E R M A N Y Control and indicating elements DX15V Pos. Designation Pos. Designation Control panel "Control panel“ on page EMERGENCY STOP push button Drilling lever... -
Page 19: Drill Chuck Guard
OPTIMUM M A S C H I N E N - G E R M A N Y Drill chuck guard Adjust the guard to the correct height before you start working. Push the drill chuck protection up or down. - Page 20 OPTIMUM M A S C H I N E N - G E R M A N Y 4.4.1 Drilling Switch on the master switch. Insert and tighten the drill bit. Clamp the workpiece. Unlock the emergency-stop.
-
Page 21: Inspection And Maintenance
OPTIMUM M A S C H I N E N - G E R M A N Y DX15V Switch off the drilling machine on the main switch or disconnect the mains plug. Move the drill sleeve down. -
Page 22: Ersatzteile - Spare Parts
OPTIMUM M A S C H I N E N - G E R M A N Y Ersatzteile - Spare parts - DX13V Ersatzteile - Spare parts Abb.5-1: Ersatzteile - Spare parts DE | GB DX13V Ersatzteile - Spare parts - DX13V Originalbetriebsanleitung Version 1.0.1 25. -
Page 23: Ersatzteilliste - Spare Part List
OPTIMUM M A S C H I N E N - G E R M A N Y Ersatzteilliste - Spare part list Menge Grösse Artikelnummer Bezeichnung Designation Qty. Size Item no. Gehäuse Housing 0302015001 Welle Shaft 0302015002 Säule Column... - Page 24 OPTIMUM M A S C H I N E N - G E R M A N Y Menge Grösse Artikelnummer Bezeichnung Designation Qty. Size Item no. Netzkabel Line cable 0302015099 Senkschraube Screw DIN 7991 - M6 x 12 Innensechskantschraube...
-
Page 25: Bohrkopf - Drilling Head
OPTIMUM M A S C H I N E N - G E R M A N Y Ersatzteile - Spare parts - DX15V Bohrkopf - Drilling head Abb.6-1: Bohrkopf - Drilling head Ersatzteile - Spare parts - DX15V DX15V DE | GB Version 1.0.1 25. -
Page 26: Säule Und Bohrtisch - Column And Drilling Table
OPTIMUM M A S C H I N E N - G E R M A N Y Säule und Bohrtisch - Column and drilling table Abb.6-2: Säule und Bohrtisch - Column and drilling table DE | GB DX15V Ersatzteile - Spare parts - DX15V Originalbetriebsanleitung Version 1.0.1 25. -
Page 27: Ersatzteilliste - Spare Part List
OPTIMUM M A S C H I N E N - G E R M A N Y Ersatzteilliste - Spare part list Menge Grösse Artikelnummer Bezeichnung Designation Qty. Size Item no. Gehäuse Housing 0302016001 Motorhalter Motor holder 0302016002 Bolzen... - Page 28 OPTIMUM M A S C H I N E N - G E R M A N Y Menge Grösse Artikelnummer Bezeichnung Designation Qty. Size Item no. Drehzahlsensor Speed sensor 0302015082 Kugellager Ball bearing 6005 2Z 0406005.2Z DIN 3771 O-Ring...
-
Page 29: Schalplan - Wiring Diagram
OPTIMUM M A S C H I N E N - G E R M A N Y Schaltplan - Wiring diagram - DX13V | DX15V Schalplan - Wiring diagram Abb.7-1: Schaltplan - Wiring diagram Schaltplan - Wiring diagram - DX13V | DX15V... -
Page 30: Ersatzteilliste Elektrische Bauteile - Spare Part List Electrical Components
OPTIMUM M A S C H I N E N - G E R M A N Y Ersatzteilliste elektrische Bauteile - Spare part list electrical components Menge Grösse Artikelnummer Bezeichnung Designation Qty. Size Item no. Steuerkarte Control board 0302015066... -
Page 31: Appendix 8.1 Copyright
Besides the legal liability claims for defects of the customer towards the seller, the manufac- turer of the product, OPTIMUM GmbH, Robert-Pfleger-Straße 26, D-96103 Hallstadt, does not grant any further warranties unless they are listed below or were promised as part of a single contractual provision. -
Page 32: Change Information Operating Manual
- Non reproducible software errors Any services, which OPTIMUM GmbH or one of its agents performs in order to fulfil any additional warranty are neither an acceptance of the defects nor an acceptance of its obli- gation to compensate. These services neither delay nor interrupt the warranty period. -
Page 33: Storage
Example: not stackable - do not stack a second packing case on top of the first one. Consult Optimum Maschinen Germany GmbH if the machine and accessories are stored for more than three months or are stored under different environmental conditions than those specified here. -
Page 34: Disposal Via Municipal Collection Facilities
Modified settings Any experiences with the geared drill which might be important for other users Recurring malfunctions Optimum Maschinen Germany GmbH Dr.-Robert-Pfleger-Str. 26 D-96103 Hallstadt Fax +49 (0) 951 - 96 555 - 888 email: info@optimum-maschinen.de DX13V | DX15V... -
Page 35: Ec - Declaration Of Conformity
