Motherboard Features

CPU
Memory
Chipset
Expansion
Slots
Graphics
IPMI_LAN
I/O Devices
•
Quad Intel E5-4600v3/v4 Series processors (Socket
®
R3 LGA 2011); each processor supports quad full-
width Intel QuickPath Interconnect (QPI) links (with
Data Transfer Rate of up to 9.6 GT/s per QPI
Note: E5-4600v4 requires Revision 2.0 BIOS
(or higher).
•
Integrated memory controller supports up to 3
TB of Load Reduction (LRDIMM), and up to 1.5
TB of Registered (RDIMM) DDR4 (288-pin) ECC
2400/2133/1866/1600 MHz memory in 48 slots
Note: Memory speed support is pending on
the processors installed in the system. For
the latest CPU/memory updates, please refer
to our website at http://www.supermicro.com/
products/motherboard.
DIMM Sizes
Up to 64GB @ 1.20V
•
Intel® PCH C612
•
One (1) PCI Express 3.0 x8 in x16 slot supported by
CPU1 (SXB2)
•
One (1) PCI Express 3.0 x32 slot supported by CPU1
(SXB1A/1B/1C)
•
One (1) PCI Express 3.0 x40 slot supported by CPU2
(SXB3A/3B/3C)
•
One (1) PCI Express 3.0 x16 slot (CPU3 Slot 1)
•
One (1) PCI Express 3.0 x16 slot (CPU4 Slot 2)
•
ASpeed 2400 BMC Controller with integrated VGA
•
One (1) IPMI-dedicated LAN for remote console inter-
face on the IO backplane to the I/O devices.
SATA Connections
•
SATA 3.0 Ten (10) SATA 3.0 connections;
I-SATA 3.0 0-3 (supported by Intel
PCH),
I-SATA 3.0 4/5 (supported by Intel
PCH with power pins built-in to sup-
port SuperDOMs),
S-SATA 3.0 0-3 (supported by Intel
PCH)
•
RAID
1-7
Chapter 1: Overview
RAID 0, 1, 5, 10 (from Intel PCH)
