Normally SIM5215&SIM5216 is mounted on customer host board. Although some ESD components have
been added in SIM5215&SIM5216, to prevent ESD, user should put some ESD components on customers'
board. The ESD components should be placed beside the connectors which human body might touch, such
as SIM card holder, audio jacks, switches, keys, etc. The following table is the SIM5215&SIM5216 ESD
measurement performance; the results are from SIMCom EVB test.
Table 44: The ESD performance measurement table (Temperature: 25 , Humidity:
Part
VBAT,GND
UART,USB
Antenna port
Other ports
6

Guide for Production

6.1 Top and Bottom View of SIM5215&SIM5216
These test points are only used for module manufacturing and testing. They are not for customer's
SIM5215&SIM5216_Hardware Design_V2.02
Contact discharge
±4KV
±2KV
±4KV
±2KV
Figure 46: Top and bottom view of SIM5215&SIM5216
Smart Machine Smart Decision
℃
Air discharge
±6KV
±6KV
±6KV
±2KV
62
45%)
