Table 3: Pin Definition - SimCom SIM5215 Hardware Design

Table 3: Pin definition

Pin No. Define
1 VBAT
2 VBAT
3 VBAT
4 GND
5 GND
6 UART_TXD
7 UART_CTS
8 UART_DCD
9 USB_VBUS
10 GPIO1
11 VRTC
12 USIM_CLK
13 USIM_RESET
14 Reserved
15 CAM_D2
16 CAM_D4
17 CAM_D6
18 CAM_D8
19 CAM_HSYNC
20 GND
21 CAM_CLK
22 CAM_STANDBY
23 SPK_P
24 SPK_N
25 EAR_P
26 EAR_N
27 HPR
28 HPL
29 RESET
30 GPIO2
31 GPIO3
32 GPIO4
33 GPIO5
SIM5215&SIM5216_Hardware Design_V2.02
Pin No. Define
70 VBAT
69 VBAT
68 VBAT
67 GND
66 GND
65 GPIO0
64 UART_RXD
63 UART_RTS
62 UART_DTR
61 UART_RI
60 USB_D_P
59 USB_D_M
58 GND
57 V_USIM
56 USIM_DATA
55 Reserved
54 CAM_D3
53 CAM_D5
52 CAM_D7
51 CAM_D9
50 CAM_VSYNC
49 CAM_PCLK
48 CAM_RESET
47 IIC_SDA
46 IIC_SCL
45 POWER_ON
44 MIC_N
43 MIC_P
42 HP_MICP
41 HKADC
40 VREG_AUX
39 SD_DATA3
38 SD_DATA2
