Yealink VC500 Quick Start Manual
Full hd video conferencing endpoint
Hide thumbs
Also See for VC500:
- Quick start manual (24 pages) ,
- Manual (4 pages) ,
- Administrator's manual (281 pages)
Related Manuals for Yealink VC500
Summary of Contents for Yealink VC500
- Page 1 按供应商要求封面做了出血3mm Yealink Network Technology CO., LTD Yealink VC500 Full HD Video Conferencing Endpoint Quick Start Guide Applies to firmware version 63.32.0.3 or later V32.3...
-
Page 3: Package Contents
Micro USB Cable C Package We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in reduced performance. VC500 endpoint can work with A package, B package or C package. - Page 4 Mount on top of a TV The endpoint may fall down when the thickness of the TV is more than 77 mm. In this situation, do not mount the endpoint on the top of a TV. Please choose the following installation method when the thickness of the TV is between 1mm and 36mm. Notice the direction of the bracket Push the bracket to an appropriate location.
-
Page 5: Mount On A Wall
Push the bracket along the track of the endpoint to an appropriate location. Steps： Stick a Velcro onto the bracket. Remove one Velcro. Put the bracket on the top of the TV. Stick a Velcro onto the back of the TV, and make sure that the bracket and the back of the TV are tightly positioned against each other. - Page 6 Screw specification: M3×8 Punch holes into the wall and then insert the expansion bolts. Steps： Secure the bracket using the T4×30 screws. Push the endpoint along the track of the bracket. Secure the endpoint onto the bracket using the M3×8 screws. Mount on a Ceiling If you choose the ceiling-mounted installation, you need to purchase a bracket separately.
-
Page 7: Remote Control And Cable Ties Installation
Screw specification: M3×8 Screw specification: 1/4”-20 UNC Steps： Push the VESA accessory along the track. Secure the VESA accessory to the endpoint using the M3×8 screws. Align the location pillar at the location hole, and then secure the bracket to the VESA accessory using the 1/4”-20 UNC screw. Mount onto a TV Stand or a Tripod You need to purchase a TV stand or a tripod separately. - Page 8 CPW90-BT bluetooth wireless microphones can work as the audio input devices. The endpoint should be used with Yealink original power adapter (48V/0.7A) only. The use of the third-party power adapter may cause the damage to the endpoint. The cable should be replaced at once if its skin is broken.
-
Page 9: Network Environment
VC Hub/Phone port on VC500 codec Wireless Sharing WPP20 Wireless Presentation Pod For more information on WPP20 wireless presentation pod, refer to Yealink WPP20 Wireless Presentation Pod Quick Start Guide. Network Environment Bandwidth Requirements Video Resolution Recommended Bandwidth Full HD 1080P 1.3Mb... -
Page 10: Configure Port Mapping
If you deploy VC500 endpoint in the branch office, do one of the following to deploy it: Option1: Deploy the VC500 endpoint following the same steps as for the head office. In this way, both inbound and outbound calls are available. -
Page 11: Troubleshooting
Intranet, you have configured port mapping on the firewall or gateway, but find that local endpoint appears black screen and you cannot hear sound when you call Yealink Demo or other endpoints. The most likely reason is that the firewall or gateway in your environment does not support the ALG feature. In this situation, please take the following actions so that... - Page 12 “Easy collaboration, high productivity.” The company’s high-quality UC terminal solutions enhance the work efficiency and competitive advantages of its customers in over 100 countries. Yealink is the world’s second-largest SIP phone provider and is number one in the China market.
