- Page 1 Black 32" Electric Compact Desk Instruction Manual SKU: DESK-V111B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v111b help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
-
Page 3: Tools Needed
TOOLS NEEDED Level DO NOT EXCEED WEIGHT CAPACITY. 88 lbs Failure to do so may result in serious injury. (40kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Insert motorized column (B) into underside of support bar (D) as shown, making sure the motor cable is placed through the slot in front. - Page 4 STEP 3 Place the desktop (C) upside down on a flat surface and position the column/base assembly upside down on the desktop. Secure the assembly using M6x12 bolts (O), and tighten with a Phillips screwdriver. STEP 4 Secure right and left brackets (I, J) to underside of desktop using M6x12 bolts (O), and tighten with a Phillips screwdriver.
- Page 5 STEP 5 Place the adapter (F) into the support bar as shown. STEP 6 Attach the control panel (H) to the left-front or right-front of the desktop using 5/8” screws (P). Connect motor and adapter cables to the control panel, and plug power cable (L) into the adapter.
- Page 6 STEP 7 Mount keyboard shelf (E) to brackets using M6x12 bolts (O), and tighten with a Phillips screwdriver. STEP 8 Attach cover (K) to keyboard tray as shown using 5/8” screws (P), making sure the cover faces up and hides the adapter.
- Page 7 STEP 9 Plug the power cable (L) into the wall. If needed, adjust feet to change level of desk. CAUTION! Keep monitor and Follow the cable Leave enough slack Raise desktop laptop base fully on routing instructions to in cable to allow for slowly to keep the desktop.
- Page 8 - 83% within < 2hr - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
