- Page 1 APP CAM FLOODLIGHT QUICK START GUIDE...
-
Page 2: Important Safety Precautions
• Never tug on the power cords. Use the plug to unplug it from the outlet. • If you wish to hardwire the App Cam Floodlight, consult with a licensed electrician and installation and wiring must be performed by a licensed electrcian in accordance with local and national wiring rules (e.g., AS/... -
Page 3: Table Of Contents
IMPORTANT SAFETY PRECAUTIONS �������������������������������������2 CONTENTS ����������������������������������������������������������������������������������3 OVERVIEW� ����������������������������������������������������������������������������������4 Features ................... 4 WHAT’S IN THE BOX? ����������������������������������������������������������������5 GETTING TO KNOW YOUR APP CAM FLOODLIGHT �������������� 6 INSTALLATION ������������������������������������������������������������������������ 7 General Placement Considerations ......... 7 Wi-Fi Operating Considerations ..........7 Installation Diagram ..............8 Installing the Camera ............... -
Page 4: Overview
OVERVIEW Uniden’s App Cam Floodlight camera works with your smartphone to create a powerful home security network. No PC interface is needed to view video on your smartphone or wireless devices. It is suitable for day or night time use. -
Page 5: What's In The Box
Image may vary slightly from the actual product. • If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model. All trademarks are registered trademarks of their respective owners. -
Page 6: Getting To Know Your App Cam Floodlight
GETTING TO KNOW YOUR APP CAM FLOODLIGHT Light Adjustment Light Lock Collar Knob 2500 Lux Floodlight Microphone Lens LED Indicator Speaker Camera Lock Collar PIR Motion Detector... -
Page 7: Installation
INSTALLATION General Placement Considerations • The cameras included are weatherproof and have an IP65 weather rating. Water can be sprayed on them and they will still work; however, the cameras cannot be submerged underwater. • Although the cameras can be exposed to the rain splashes, it is recommended that, if they are used outdoors, they be mounted under some type of cover like a patio overhang or an eave. -
Page 8: Installation Diagram
Installation Diagram... -
Page 9: Installing The Camera
4. Peel the backing off the adhesive Waterproof Cushion and stick it to the back of the App Cam Floodlight. 5. Place the App Cam Floodlight (make sure the “UP” arrow on the back is pointing up) against the wall, aligning the center mounting holes and lock it securely with the provided long mounting screw and washer. -
Page 10: Initial Camera Setup
• You must have an available Wi-Fi-enabled Smartphone (Android or iOS smartphone). • The App Cam Floodlight and your mobile device must within the same Wi-Fi network range for initial setup (ideally within 3m from the router). • Wi-Fi router connection is 2.4GHz and password if any. - Page 11 3. When you open the My Uniden app for the first time, you will see the login page. Tap the “Register” button to create a new My Uniden account. Once you select Register, you’ll be prompted to add your email address, and tap “Get Verification Code Button”.
- Page 12 6. You will see the Home tab. To pair a device, tap the “Add Device” button or the “+” button on the top right-hand side of the screen if you already have shared access or a paired device. Once you have tapped the Add Device button, tap the Smart Camera icon to set up the App Cam Floodlight.
- Page 13 After you hear the voice prompt from the camera, please press “I heard a Prompt” to continue. Please wait while the app is configuring your App Cam floodlight. Once completed, you’ll be prompted to name your camera and tap “Done”. You Floodlight.
-
Page 14: Adjusting The Floodlight And Camera
Adjusting the Floodlight and Camera Loosen the adjustment knobs or the locking nut/collar on the floodlight and the camera Adjust the viewing angle of camera and the pointing direction of the flood- light and tighten the knobs once the adjustment is completed. Router... -
Page 15: Troubleshooting
TROUBLESHOOTING If��� Try This��� The camera does Make sure the Wi-Fi router supports DHCP not find or connect protocol. the router. Make sure that the DHCP option is turned on. Make sure the camera and your mobile device connect to the same Wi-Fi router. Make sure you selected the correct 2.4GHz router only in your device Wi-Fi setting. -
Page 16: Specifications
SPECIFICATION Item Specification Image Sensor 1/2.7” F2.8mm Colour CMOS Recording Resolution 1920 x 1080 15fps, 640 x 480 15 fps Viewing Angle 150°(D) Night Vision Video Compression H.264 Audio Two-way talk Audio Compression Illuminance up to 2500lux Colour Temperature 5000K Lamp Life Cycle 36000h Lamp Case Material... - Page 17 App Cam Floodlight Important: Satisfactory evidence of the original purchase is required for warranty service. Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor: The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”).
- Page 18 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the address shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 20 ©2019 Uniden Australia Pty Ltd Printed in PRC v1.0...
