Summary of Contents for Uniden App Cam Home
- Page 1 App Cam Home Quick Start Guide...
-
Page 2: What's In The Box
What’s in the Box Power Adapter App Cam Home Mounting Plate Quick Start Guide Reset Needle Mounting Template Screw Kit... -
Page 3: General Introduction
General Introduction Speaker Power Port LAN Port Lens Status LED Built-in Mic Micro SD Card Slot Reset Button Note: Rotate the lens to find the reset button and SD Card Slot Press more than 5 seconds to restore the device to factory settings Blue LED Status Blinking: Network connection failed/Network is not configured. -
Page 4: Install Uniden Solo App
Install Uniden Solo App There are two ways to get the Uniden Solo App: • Search “Uniden Solo” in App Store (for iOS), download and install the app. • Search “Uniden Solo” in Google Play (for Android), download and install the app. - Page 5 Note: If you prefer network cable connection, tap “Choose Network Cable Connection”. Please plug in the power cable and the ethernet cable (not included) before ac- cessing the camera and follow the prompts on the screen. You have the option to set up WiFi connection eventhough you use cable connection.
- Page 6 4. Select “I have heard the voice prompt” 5. Enter the Wi-Fi password of the selected and tap “Next” to enter the next page. Wi-Fi network and tap “Next” to continue. If you did not hear the voice prompt, please press “I didn’t hear the voice prompt”...
- Page 7 Scan succeeded. Camera is connecting to the router. Please wait. 6. Tap “Scan Now” to proceed. A QR code will be generated on the phone. Please place the QR code on your phone towards App Cam Solo Pro camera’ lens at a distance of about 20cm to let the camera scan the QR code.
- Page 8 Connection to the router failed! 7. If you hear the above voice prompt, please ” press “I heard ‘Wi-Fi connection failed’ for help. Connection to the router succeeded. 8. If you hear the above voice prompt, please press Select “I have heard the voice prompt” and tap “Next”...
- Page 9 9. Create a password (at least 6 characters), name the camera and set the DST time. Then start live view or go to “Device Settings” for more configurations. Note: “Name your camera” field refers to the display name of the camera rather than the login username.
-
Page 10: Device Menu
Device Menu Menu Add New Device Device Settings Access Live View... -
Page 11: How To Mount The Camera
How to Mount the Camera Step 1 Drilling two screw holes on the wall according to the mounting hole template. Step 2 Insert the two plastic anchors into the holes on the wall. Step 3 Secure the base unit in place by tightening the screws into the plastic anchors. - Page 12 Step 4 Align the camera with the bracket, then turn the camera unit clockwise to lock it in position. NOTE: 1. Turn the camera anticlockwise to remove it from the wall. 2. In case your camera is mounted upside down, the picture will need to be rotated as well.
- Page 13 Important Notes for Reducing False Alarms For reducing false alarms, please note that: • Do not install the camera facing any objects with bright lights, including sunshine, bright lamplights, etc. • Do not place the camera too close to a place where there are frequently moving vehicles.
-
Page 14: Troubleshooting
Troubleshooting Camera is not turning on If your camera is not turning on, please apply the following solutions: • Plug the camera to another outlet. • Use another 5V pwoer adapter to power up the camera. Fail to scan the QR code on the phone If the camera failed to scan the QR code on your phone, please apply the following solutions: •... -
Page 15: Specifications
Specifications Model App Cam Home Image Sensor CMOS Image Sensor Video Resolution 2560 x 1440 (4 Megapixel) Video Frame Rate up to 20 fps Video Compression H.264 Video & Audio Viewing Angle Diagonal: 110° Pan & Tilt Angle Horizontal: 355° Vertical: 50°... -
Page 16: Warranty
The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”). Terms of Warranty: Uniden Aust warrants to the original retail purchaser only that the Uniden App Cam Home (“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period, subject to the limitations and exclusions set out below. - Page 17 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 20 THANK YOU FOR BUYING A UNIDEN PRODUCT © 2020 Uniden Australia Pty Limited V1.0 Printed in PRC...
