Summary of Contents for Uniden App Cam Solo 4G PT
- Page 1 App Cam Solo 4G PT Quick Start Guide...
- Page 2 What’s in the Box Plastic Mount App Cam Solo 4G PT Antenna Power Cable Quick Start Guide Mounting Template Screw Kit...
- Page 3 General Introduction Status LED IR LED Lens Daylight Sensor Built-in PIR Sensor Built-in Mic Nano Sim Card Slot Rotate the camera’s lens to find the reset hole, SIM card slot and SD card slot. Reset Hole Press the reset button with a pin to restore the device to factory settings.
- Page 4 Insert the SIM Card and SD Card 1. Rotate the camera lens, and remove the rubber cover. 2. Insert the SIM card. • The SIM card slot is above the SD card slot. When inserting it in, please note that gold contacts on the SIM card shall face down, and the trimmed corner shall be inside the camera.
- Page 5 Tips on How to Choose the Right SIM Card Required size of a nano SIM card: • The SIM card shall support WCDMA and FDD LTE. 12.3mm • Some SIM cards have a PIN code. Please use your smartphone to disable the PIN first. •...
- Page 6 2. Wait a few seconds and a red light will be on and solid for a couple of seconds. Then it will go off. 3. A blue LED will flash for a few seconds and then go solid before going out. You will hear a voice prompt “Network connection succeeded”, which means the camera has been successfully...
- Page 7 Note: You may also run into the following situations: Voice Prompt Camera Status Solutions 1. Check if the SIM card is facing “SIM card cannot be Camera cannot the reverse direction. recognized” recognize this SIM card. 2. Check if the SIM card is not fully inserted and insert it again.
- Page 8 2. Charge the camera with power adapter. Uniden solar panel. * The battery is built-in,please do not remove it from the camera * Please note that the USB charger and Solar Panel are NOT included in the package. You can buy the solar panel separately.
- Page 9 1. Please charge the rechargeable battery with a standard and high-quality DC 5V or 9V battery charger. 2. If you want to power the battery via the solar panel, please note that the battery is ONLY compatible with Uniden solar panel.
- Page 10 Install Uniden Solo App There are two ways to get the Uniden Solo App: • Search “Uniden Solo” in App Store (for iOS), download and install the app. • Search “Uniden Solo” in Google Play (for Android), download and install the app.
- Page 11 3. After you created a password for your camera, please follow the steps to sync the time, and then start live view or go to “Device Settings” 12:00 Menu Solo 4G Add New Device Enable/Disable PIR Motion Sensor (the PIR sensor is enabled by default) Device Settings Access Live View Battery Status...
- Page 12 Attention for Camera Installation For outdoor use, please install the App Cam Solo 4G PT upside down in order to maximize the weatherproof performance and the PIR motion sensor’s efficiency. For indoor use, the camera can be placed upright, but please make sure to place it at a maximum of 2.5 meters from the ground.
- Page 13 • PIR Sensor Installation Angle Pease install the camera 2-3 meters above the ground. The detection range of the motion sensor would be maximized at such a height. For effective motion detection, please install the camera angularly and the angle between the PIR sensor and the detected object must be larger than 10°.
- Page 14 Important Notes for Reducing False Alarms For reducing false alarms, please note that: • Do not install the camera facing any objects with bright lights, including sunshine, bright lamplights, etc. • Do not place the camera too close to a place where there are frequently moving vehicles.
- Page 15 How to Install Plastic Mount Step 1 Drill holes in accordance with the mounting hole template and screw the plastic mount to the wall. If you are mounting the camera to a masonry or on any other hard surface, remember to insert the plastic anchors into the hole.
- Page 16 How to Mount the Camera to the Ceiling Loosen the screw on security mount and remove the ceiling bracket from the mount. Install the bracket to the ceiling and attach the camera to it.
- Page 17 How to Attach the Camera to a Tree You are allowed to strap the camera to a tree with both the security mount and ceiling bracket. Thread the provided strap to the plate and fasten it to a tree. Next, attach the camera to the plate and you are good to go.
- Page 18 If the PIR sensor fails to trigger any kind of alarm within the covered area,please apply the following solutions: • On Uniden Solo App and go to Device Settings-> PIR Settings. Check if the Time Schedule, Sensitivity and Action settings are enabled and set properly.
- Page 20 Specification Model App Cam Solo 4G PT Image Sensor Starlight CMOS Image Sensor Video Resolution 1920 x 1080 (2.0Megapixel) 15 fps Video Compression H.264 Viewing Angle Diagonal: 105° Video Pan Angle 355° Tilt Angle 140° PIR Detecting Distance Up to 10 Meters PIR Detecting Angle Horizontal: 90°...
- Page 21 Battery Lithium battery/3.6V, 6500mAh Power Compatible Solar Panel SPS-01/SPS-02 Storage SD Card Supports up to 64GB micro SD card, min class 10 Size Φ98 x 112 mm Size & Weight Weight 485 g (including battery) Temperature Operating Temperature : -10°C~+55°C Other Parameters Humidity Operating Humidity: 20% ~ 85%...
- Page 22 Product 2 Year If a warranty claim is made, this warranty will not apply if the Product is found by Uniden to be: A. Damaged or not maintained in a reasonable manner or as recommended in the relevant Owner’s Manual;...
- Page 23 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 24 THANK YOU FOR BUYING A UNIDEN PRODUCT © 2020 Uniden Australia Pty Limited V1.0 Printed in PRC...
