- Page 1 App Cam Solo PT Quick Start Guide...
-
Page 2: What's In The Box
What’s in the Box Plastic Mount App Cam Solo PT Antenna Metal Mount Quick Start Guide Mounting Template Screw Kit Power Cable... -
Page 3: Optional Accessories
Optional Accessories Solar Panel (SPS-01) Visit the App Cam Solo PT page on the website for more information on the availability of optional accessories: www.uniden.com.au for Australia... -
Page 4: General Introduction
General Introduction Speaker Status LED Lens Built-in PIR Sensor Daylight Sensor Built-in Mic Reset Hole Micro SD Card Slot Battery Status LED Micro USB Port Antenna On/Off Switch Red LED (WiFi connection failed) Blue LED (WiFi connection succeeded) Blinking: Standby status Blinking: Standby status On: Working status On: Working status... -
Page 5: Install The Antenna
Install the Antenna Please install the Antenna to the camera. Turn the antenna base in a clockwise motion to connect. Leave the antenna in a vertical position for best reception. Turn on the Camera The camera is turned off by default, please turn it on before setting up the camera. Note: If the camera will not be in use for a very long time,... -
Page 6: Charge The Battery
Charge the Battery 1. Charge the battery with a 2. Charge the camera with the power adapter. SPS-01 solar panel. * The battery is built-in,please do not remove it from the camera * Please note that the USB charger and Solar Panel are NOT included in the package. You can buy the solar panel separately. - Page 7 Important Safeguards on Rechargeable Battery Use App Cam Solo PT is not designed for 24/7 full capacity running or around-the-clock live streaming. It’s designed to record motion events and remotely view live streaming only when you need it. 1. Please charge the rechargeable battery with a standard and high-quality DC 5V or 9V battery charger.
-
Page 8: Install Uniden Solo App
Install Uniden Solo App There are two ways to get the Uniden Solo App: • Search “Uniden Solo” in App Store (for iOS), download and install the app. • Search “Uniden Solo” in Google Play (for Android), download and install the app. - Page 9 “Access Cameras” without reconfiguring it. App Cam Solo PT Camera can only connect to 2.4GHz Wi-Fi. 2. Scan the QR code on the back 3. Click “Connect to Wi-Fi” to of the camera.
- Page 10 4. Click the button “I heard the voice” to 5. Enter the Wi-Fi password of the selected enter the next page. Wi-Fi network and tap “Next” to continue. If you did not hear the voice prompt, please press “I didn’t hear the voice” for help.
- Page 11 6. A QR code will be generated on the phone. Please place the QR code on your phone towards App Cam Solo PT camera’ lens at a distance of about 30cm to let the camera scan the QR code. Please make sure that you’ve ripped the protection film of the camera’s lens.
- Page 12 Connection to the router failed! 7. If you hear the above voice prompt, please ” press “I heard ‘Wi-Fi connection failed’ for help. Connection to the router succeeded. 8. If you hear the above voice prompt, please press “I heard ‘Connection to the router succeeded.’...
- Page 13 9. Create a password (at least 6 characters), name the camera and set the DST time. Then start live view or go to “Device Settings” for more configurations. Note: “Name your camera” field refers to the display name of the camera rather than the login username.
-
Page 14: Device Menu
Device Menu Menu Add New Device Enable/Disable PIR Motion Sensor (the PIR sensor is enabled by default) Device Settings Access Live View Battery Status... - Page 15 Attention for Camera Installation For outdoor use, please install the App Cam Solo PT upside down in order to maximize the weatherproof performance and the PIR motion sensor’s efficiency. For indoor use, the camera can be placed upright, but please make sure to place it at a maximum of 2.5 meters from the ground.
- Page 16 • PIR Sensor Installation Angle When installing the camera, please install the camera angularly (the angle between the sensor and the detect- ed object is larger than 10°) for effective motion detec- tion. If the moving object approaches the PIR sensor vertically, the sensor may not detect the motion events.
- Page 17 Important Notes for Reducing False Alarms For reducing false alarms, please note that: • Do not install the camera facing any objects with bright lights, including sunshine, bright lamplights, etc. • Do not place the camera too close to a place where there are frequently moving vehicles.
- Page 18 the camera to the proper direction. How to Install Metal Mount Step 1 Step 2 Step 2 Step 1 Step 1 Step 2 Loosen the adjusting control on Loosen the adjusting control on the Screw the camera bracket Screw the metal mount into Loosen the adjusting control on the metal mount and adjust the Screw the metal mount into...
- Page 19 How to Install Plastic Mount Step 1 Step 2 Step 3 Step 1 Step 2 Step 3 Step 1 Step 2 Step 3 Screw the antenna to the camera. Loose the screw cap and unfold Screw the plastic mount into Screw the antenna to the camera.
-
Page 20: Specification
Specification Model App Cam Solo PT Image Sensor Sony Starlight CMOS Image Sensor Video Resolution 1920 x 1080 (2.0Megapixel) 15 fps Video Compression H.264 Viewing Angle Diagonal: 105° Pan Angle 355° Video Tilt Angle 140° PIR Detecting Distance Low: 2-4 Meters, Mid: 4-6 Meters, High: 6-10 Meters PIR Detecting Angle Horizontal: 90°... - Page 21 SD Card Supports up to 64GB micro SD card, min class 10 Storage Size Φ98 x 112 mm Size & Weight Weight 470 g (including battery) Temperature Operating Temperature : -10°C~+55°C Humidity Operating Humidity: 20% ~ 85% Other Parameters Waterproof Level IP65 Weatherproof...
- Page 22 The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”). Terms of Warranty: Uniden Aust warrants to the original retail purchaser only that the Uniden App Cam Solo PT (“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period, subject to the limitations and exclusions set out below.
- Page 23 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 24 THANK YOU FOR BUYING A UNIDEN PRODUCT © 2019 Uniden Australia Pty Limited V1.0 Printed in PRC...
