Summary of Contents for Uniden App Cam Solo+

  • Page 1 App Cam Solo Quick Start Guide...

  • Page 2: What's In The Box

    What’s in the Box App Cam Solo+ Rechargeable Silicone Weatherproof Flat Mount Screw Mount Battery Camera Cover Mounting Strap Reset Needle Screw Kit Mounting Template Power Cable The camera and the rechargeable battery are packed separately in the same package. Please dress the camera with the Silicone Cover for better weatherproof performance when you install the camera outdoors.

  • Page 3: Optional Accessories

    Optional Accessories Solar Panel Battery Pack (SPS-01) (BPS-01) Visit the App Cam Solo+ page on the website for more information on the availability of optional accessories: www.uniden.com.au for Australia...

  • Page 4: General Introduction

    General Introduction Micro SD Card Slot Reset Button Daylight Sensor Lens Status LED Built-in Mic Built-in PIR Motion Sensor Speaker Red LED (WiFi connection failed) Blue LED (WiFi connection succeeded) Blinking: Standby status Blinking: Standby status On: Working status On: Working status...
  • Page 5 Install the Rechargeable Battery to the Camera Please press the button (on the top of the back housing), and slide the back housing downward to close it. The button needs to be closed firmly for ultimate weatherproof performance. For weatherproof performance, always cover the charging port with the rubber plug...

  • Page 6: Charge The Battery

    1. You can charge the battery when it’s installed to the camera. 2. You can charge the battery separately. 3. You can charge the battery with Uniden Solar Panel (SPS-01). Please note that the solar panel is NOT included in the package.
  • Page 7 3. Please charge the battery in temperature between 0˚C and 45˚C Important Note Uniden App Cam Solo+ is not designed for 24/7 full capacity running or around-the-clock live streaming. It’s designed to record motion events and remotely view live streaming only when you need it.

  • Page 8: Install Uniden Solo App

    Install Uniden Solo App 12:00 12:00 There are two ways to get the Uniden Solo App: • Search “Uniden Solo” in App Store (for iOS), download and install the app. • Search “Uniden Solo” in Google Play (for Android), download and install the app.
  • Page 9 12:00 12:00 12:00 12:00 12:00 12:00 12:00 12:00 Uniden Wi-Fi Note: When the setup for the camera is completed, your family can access the camera simply by clicking “Access Cameras” without reconfiguring it. 2. Scan the QR code on the back 3.
  • Page 10 12:00 12:00 12:00 12:00 12:00 12:00 Uniden Wi-Fi Uniden Wi-Fi 4. Click the button “I have heard the voice 5. Enter the Wi-Fi password of the selected prompt” to enter the next page. Wi-Fi network and press “I have entered the correct information”...
  • Page 11 12:00 12:00 About 20cm Uniden Wi-Fi I heard “Connection to the r Scan succeeds. Camera is connecting to the router. Please wait. 6. A QR code will be generated on the phone. Please place the QR code on your phone towards App Cam Solo+ camera’...
  • Page 12 12:00 12:00 12:00 12:00 12:00 12:00 12:00 I heard “Connection to the router succeeded.” I heard “Connection to the router succeeded.” I heard “Connection to the router failed! ” I heard “Connection to the router failed! ” Connection to the router failed! Connection to the router succeeded.
  • Page 13 12:00 12:00 12:00 12:00 Solo+ I heard “Connection to the router succeeded.” 9. Name your camera and create a password (at least 6 characters), tap “Create Password”, slide the page to read the tips and tap “finish” to start the Live View. Tap to go to the “Devices”...
  • Page 14 12:00 12:00 Solo+ 10. Please tap the camera and follow the steps to sync the time, and then start live view or go to “Device Settings” for more configurations.

  • Page 15: Device Menu

    Device Menu 12:00 Menu Solo+ Add New Device Enable/Disable PIR Motion Sensor (the PIR sensor is enabled by default) Device Settings Access Live View Battery Status...
  • Page 16 The default sensitivity of the PIR sensor is at “Mid” and the detecting distance is 6 meters. If you want to adjust the sensitivity, please launch your Uniden Solo App, and then click “Device Settings” -> “PIR Settings” and click the “save” button to save the settings.
  • Page 17 Important Notes for Reducing False Alarms For reducing false alarms, please note that: • Do not install the camera facing any objects with bright lights, including sunshine, bright lamplights, etc. • Do not place the camera too close to a place where there are frequently moving vehicles.
  • Page 18 Cover the Monitoring Area When installing the camera, it’s not suggested to make the PIR sensor vertically face the moving object. Please note that if the moving object It’s not suggested to make approaches the PIR sensor vertically, the PIR sensor the PIR sensor vertically face the moving object.
  • Page 19 The Ideal Viewing Distance The ideal viewing distance is 2-10 meters, which enables you to recognize a human. Ideal Viewing Distance: 2-10 meters...
  • Page 20 How to Install the Skin to the Camera Please dress the camera with the skin for better weatherproof performance when you install the camera outdoors. Step 1 Step 2 Step 3 Please dress the App Cam Solo+ The cover has an anti-falling safety Stick the camera on the wall mount camera with the silicone cover provid- rope.

  • Page 21: How To Install

    How to Install Wall Mount Step 1 Step 2 Press the button to release the Screw the security mount plate into the wall. plate from the screw mount. Step 3 Step 4 Step 5 Latch the security mount on its plate Press the security mount button Screw the camera, adjust its direction (Make sure the top edge of the back-...
  • Page 22 Tree Mount Step 1 Step 2 Step 3 Press the button to release the Thread the hook & strap through Fasten the warp strap to the tree. plate from the screw mount. the slots. Step 4 Step 5 Step 6 Latch the security mount on its plate Press the security mount button Screw the camera, adjust its direction...

  • Page 23: How To Remove The Camera

    How to Remove the Camera Step 1 Step 2 Press the security mount button Unscrew the camera from the to pull the mount out. screw mount.
  • Page 24 Accessories and Battery 90 Days If a warranty claim is made, this warranty will not apply if the Product is found by Uniden to be: A. Damaged or not maintained in a reasonable manner or as recommended in the relevant Owner’s Manual;...
  • Page 25 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
  • Page 28 THANK YOU FOR BUYING A UNIDEN PRODUCT © 2018 Uniden Australia Pty Limited V1.1 Printed in PRC...
