Nav TV MY-CUE Installation Manual

BHM
12/3/13
NTV-DOC150
th
3950 NW 120 Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
www.nav-tv.com info@nav-tv.com
MY-CUE Kit
NTV-KIT457
Overview
The MY-CUE Kit allows the user to add up to 3 audio/video inputs and a backup camera input to
the factory media screen in select GM vehicles equipped with either the MYLINK or CUE media
systems. This kit has a dedicated rear view camera input, 3 composite (RCA) audio/video inputs,
an RGB input and an AV output with AV switching. Audio integration requires that the vehicle
have a factory audio input.
Kit Contents
AV Input Harness
LVDS Video cable
MY-CUE Interface
Remote
RGB Input cable
IR Eye Harness
Power/CAN Harness Input Toggle Switch
:
Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
1 | P a g e
