About SDM-8400 Unit

Unit chassis
1 Ethernet port (requires customer-supplied LAN
cable)
4 or 8 serial ports (require custom serial cables)
1 console port, with console cable
1 power supply, with removable power cable (UAC)
1 rackmount kit
Ethernet
Console port
LAN port
System status
LAN status
LEDs
LEDs
Ethernet
Console port
LAN port
System status
LAN status
LEDs
LEDs
4-2
Item
Table 4-1: Chapter references per Unit Item
Product Serial Number
Figure 4-1: Rear View of the SDM-8400 UAC (8-port version)
Product Serial Number
Figure 4-2: Rear View of the SDM-8400 DC version (8-port version)
Serial ports (8)
Serial ports (8)
Details
"Unit Chassis" on page 4-3
"Ethernet Port" on page 4-5
"Serial Port" on page 6-2
"Console Port" on page 4-7
"Power Supply" on page 4-9
"Rackmount Kit" on page 4-11
AC connector
DC connector
