6.5

Custom Serial Cable Specifications

6.5.1

V.35/V.11 Cables

6.5.2

TIA-232 (V.24) Cables

6.5.3

X.21 Cables

Memotec
In the following sections the Ordering part number is required for ordering
NOTE:
extra cables. The Stock number is printed on the cable.
• HD-26 male connector at one end for connection to the SDM-8400 serial port
• ISO-2593 female (DCE) or male (DTE) connector at the other end for connection
to the V.35/V.11 equipment
• Use the DCE cable for connection to a male connector on the V.35/V.11
equipment (typically a DTE device)
Ordering part number 161-0893-001, Stock number 502-0940-006.
• Use the DTE cable for connection to a female connector on the V.35/V.11
equipment (typically a DCE device).
Ordering part number 161-0894-001, Stock number 502-0941-006.
• HD-26 male connector at one end for connection to the SDM-8400 serial port
• DB-25 female (DCE) or male (DTE) connector at the other end for connection to
the TIA-232 (V.24) equipment
• Use the DCE female cable for connection to a male connector on the TIA-232
(V.24) equipment (typically a DTE device)
Ordering part number 161-0897-001, Stock number 502-0944-006.
• Use the DTE male cable for connection to a female connector on the TIA-232
(V.24) equipment (typically a DCE device)
Ordering part number 161-0898-001, Stock number 502-0945-006.
An X.21 cable has a 4-40 screw on the DB-15 connector.
NOTE:
• HD-26 male connector at one end for connection to the SDM-8400 serial port
• DB-15 female (DCE) or male (DTE) connector at the other end for connection to
the X.21 equipment
Serial Port and User Equipment Connection
6-5
