3.4

Connecting the Console Terminal

A console cable kit is provided with the SDM-8400 product package to connect the SDM-
8400 to the console terminal. The kit includes a standard TIA-232 (V.24) straight-through
cable with RJ-45 male connectors at both ends (Ordering part number: 502-0808-014) and
a TIA-232 (V.24) adaptor for console terminal connection, RJ-45 female to DB-9 female
(Ordering part number: 502-0635-001). See
To connect the console terminal to the SDM-8400 unit:
1.
2.
3.
3.4.1

Important Console and Modem Settings for Startup

The console port performs autobaud detection when in auto-sensing mode. The SDM-
8400 will set the speed of the console port as soon as it detects an active connection.
Once the initialization sequence has completed successfully, the SDM-8400 enters auto-
sensing mode automatically. At that point, you can change your console speed, if desired.
3.4.2

Activating the Console Connection

To activate the console connection:
Memotec
Install one end of the console cable onto the SDM-8400 console port, labelled
on the rear panel. See Figure
version)" on page 4-2.
Connect the other end of the console cable to the RJ-45 female side of the terminal
adaptor.
Plug the DB-9 female side of the terminal adaptor into a COM port on the console
terminal or PC, or to a modem for dialup connection to a remote console.
Caution:
For trouble-free startup, you should set the console terminal and
modem as follows:
• Console terminal: The default console speed is 9600 bps during bootstrap ini-
tialization, boot sector validation and system initialization. Set your console ter-
minal emulator to 9600 bps to view all SDM-8400 system status messages on-
screen during the initialization sequence (described on
up" on page 3-8).
• Modem: Configure your modem with the following AT commands:
- to ignore DTR. The SDM-8400 cannot supply DTR to the modem
at&d0
when in auto-sensing mode (the default setting).
- for Auto Answer mode
ats0=1
- to save the modem configuration.
at&w0
• Available console speeds are 1200, 2400, 4800, 9600, 19200, 28800, 38400,
57600 and 115200 bps. The equipment you connect to the console port must
operate at one of these speeds.
"Console Cable" on page 4-7
4-1, "Rear View of the SDM-8400 UAC (8-port
Hardware Installation
for details.
"System Status on Power-
3-9
CSL
