7. PARTS

1 2 3 4 5
7
9 10 11
6
1. Power switch
2. Power input
3. Power output
8
4. DMX input
5. DMX output
12
6. Warning LEDs
7. Display
8. DMX LED
9. MENU button
13 14 15 16
10. UP button
11. DOWN button
12. RESET button
13. Cannon connection
14. Indicator LED
15. Turning lock
16. Cannon srew nut
17. Right screw nut
Version 1.0
17
