- Page 1 ECM-BDWH Intel® Core ™ Processors 3.5” Micro Module with Intel® QM87 Chipset User’s manual Ed – 16 September 2015 Part No. E2047392400R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
- Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 ECM-BDWH User’s Manual...
-
Page 5: Table Of Contents
SATA power connector (SATA_PWR1) ................31 2.4.19 EC Debug connector (CN2) ..................... 31 2.4.20 LVDS connector (JLVDS1) ....................32 2.4.21 On-board box header for USB3.0 (JUSB3/4) ..............33 2.4.22 On-board box header for USB3.0 (JUSB5/6) ..............33 ECM-BDWH User’s Manual 5... - Page 6 Serial Port Console Redirection ................. 56 3.6.2.10 SATA Configuration ..................56 3.6.2.11 Thermal Configuration ..................57 3.6.2.11.1 Platform Thermal Configuration................58 3.6.2.12 Network Stack ....................59 3.6.2.13 CSM Configuration.................... 60 3.6.2.14 USB Configuration .................... 61 3.6.3 Chipset......................... 62 6 ECM-BDWH User’s Manual...
- Page 7 Install ME Driver ................... 76 Install USB 3.0 Driver ..................77 Install VGA Driver ..................78 Install Audio Driver (For Realtek ALC892) ............79 Install Ethernet Driver (For Intel I210AT and I217LM) ........80 5. Mechanical Drawing ..................... 81 ECM-BDWH User’s Manual 7...
-
Page 8: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x 3.5” ECM-BDWH Micro Module 1 x AUX-056 daughter board ... -
Page 9: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment September 2015 Avalue Initial Release ECM-BDWH User’s Manual 9... -
Page 10: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with ECM-BDWH series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 11: System Specifications
AC97 Codec Realtek ALC892 Supports 5.1-CH Audio Ethernet 1 x Intel I210AT GbE controller LAN Chip 1 x Intel I217LMGbE PHY Ethernet Interface 10/100/1000 Base-Tx compatible CMOS Battery CR2032 1 x RS232/422/485 Rear I/O 2 x USB3.0 ECM-BDWH User’s Manual 11... - Page 12 (Please consult product engineers for the production feasibility if 5.7" x 4" (146mm x 101mm) the size is larger than 410x360mm or smaller than 80x70mm) Weight 0.44lbs (0.2kg) Note: Specifications are subject to change without notice. 12 ECM-BDWH User’s Manual...
-
Page 13: Architecture Overview - Block Diagram
User’s Manual 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of ECM-BDWH. ECM-BDWH User’s Manual 13... -
Page 14: Hardware Configuration
ECM-BDWH 2. Hardware Configuration 14 ECM-BDWH User’s Manual... -
Page 15: Product Overview
User’s Manual 2.1 Product Overview ECM-BDWH User’s Manual 15... - Page 16 ECM-BDWH 16 ECM-BDWH User’s Manual...
-
Page 17: Installation Procedure
Note: Make sure the heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause the system to hang or unstable ECM-BDWH User’s Manual 17... -
Page 18: Main Memory
ECM-BDWH 2.2.1 Main Memory ECM-BDWH provides one 204-pin DDR3L SODIMM socket, supports up to 8GB DDR3L 1333/1600 SDRAM. SODIMM (Rear side) Make sure to unplug the power supply before adding or removing SODIMMs or other system components. Failure to do so may cause severe damage to both the board and the components. - Page 19 (2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by touching a grounded metal object briefly. ECM-BDWH User’s Manual 19...
-
Page 20: Jumper And Connector List
CPU_FAN1 CPU fan connector 4 x 1 wafer, pitch 2.54 mm HDMI1 HDMI connector RS422_1 COM 1 RS-422-485 connector 3 x 2 wafer, pitch 2.00 mm JAUDIO1 Audio connector 6 x 2 wafer, pitch 2.00 mm 20 ECM-BDWH User’s Manual... - Page 21 1 x 4 wafer, pitch 2.50 mm SATA1 Serial ATA connector 1 SATA2 Serial ATA connector 2 SYS_FAN1 System fan connector 4 x 1 wafer, pitch 2.54 mm VGA1 VGA connector D-sub 15-pin, female MPCIE2 Mini-PCI connector DDR3 SODIMM connector ECM-BDWH User’s Manual 21...
-
Page 22: Setting Jumpers & Connectors
ECM-BDWH 2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (JBAT1) Protect* Clear CMOS * Default 2.4.2 COM 1 pin 9 signal select (JRI1) Ring* +12V * Default 22 ECM-BDWH User’s Manual... -
Page 23: At/ Atx Input Power Select (Jat1)
User’s Manual 2.4.3 AT/ ATX Input power select (JAT1) * Default 2.4.4 LCD backlight brightness adjustment (JVR1) PWM Mode* DC Mode * Default ECM-BDWH User’s Manual 23... -
Page 24: 5Vsb Connector In Atx (Pwr_Sb1)
ECM-BDWH 2.4.5 5VSB connector in ATX (PWR_SB1) Signal PSON_ATX# +ATX5VSB 2.4.6 Battery connector (BT1) Signal +3.3V 24 ECM-BDWH User’s Manual... -
Page 25: Cpu Fan Connector (Cpu_Fan1)
User’s Manual 2.4.7 CPU fan connector (CPU_FAN1) Signal +12V Tachometer0 FAN_PWM0 2.4.8 System fan connector (SYS_FAN1) Signal +12V Tachometer1 FAN_PWM1 ECM-BDWH User’s Manual 25... -
Page 26: Com 1 Rs-422-485 Connector (Rs422_1)
COM 1 RS-422-485 connector (RS422_1) Signal PIN PIN Signal 485_422TX1- 422RX1- 485_422TX1+ 422RX1+ Note: This connector is available after modify the mode of COM1 in BIOS setting 2.4.10 LCD inverter connector (JBKL1) Signal +12V BKLEN VBRIGHT 26 ECM-BDWH User’s Manual... -
Page 27: Audio Connector (Jaudio1)
Signal MIC1-JD LINE1-JD FRONT-JD MIC1-L-IN MIC1-R-IN LINE1-L-IN LINE1-R-IN FRONT-L-OUT FRONT-R-OUT 2.4.11.1 Signal Description – Audio connector (JAUDIO1) Signal Signal Description LINE1_JD AUDIO IN (LINE_RIN/LIN)sense pin FRONT_JD AUDIO Out(ROUT/LOUT) sense pin MIC1_JD MIC IN (MIC_RIN/LIN) sense pin ECM-BDWH User’s Manual 27... -
Page 28: Low Pin Count Connector (Jlpc1)
Low pin count connector (JLPC1) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 LPC_RESET# LPC_AD2 LPC_LFRAME# LPC_AD3 CLK_PCI_LPC SERIRQ +V5S +V5A LPC_LDRQ0# 2.4.13 Serial port 2 connector (COM2) Signal PIN PIN Signal NRXDB NDCDB# NDTRB# NTXDB NDSRB# NCTSB# NRTSB# NRIB# 28 ECM-BDWH User’s Manual... -
Page 29: General Purpose I/O Connector (Jdio1)
User’s Manual 2.4.14 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_DATA_9555 10 SMB_CLK_9555 DIO_GP13 DIO_GP23 DIO_GP12 DIO_GP22 DIO_GP11 DIO_GP21 DIO_GP10 DIO_GP20 2.4.15 Miscellaneous setting connector (JFP1) Signal PWBT RST# PWR-LED- PWR-LED+ HDD-LED+ HDD-LED- COPEN# ECM-BDWH User’s Manual 29... -
Page 30: Spi Connector (Jspi1)
ECM-BDWH 2.4.16 SPI connector (JSPI1) Signal Signal HOLD# SPI_SI SPI_SO SPI_CLK SPI_CS0# +3.3V 2.4.17 Power connector (PWR1) Signal PIN PIN Signal +12V +12V 30 ECM-BDWH User’s Manual... -
Page 31: Sata Power Connector (Sata_Pwr1)
User’s Manual 2.4.18 SATA power connector (SATA_PWR1) Signal 2.4.19 EC Debug connector (CN2) Signal EC_SMCLK_DEBUG EC_SMDAT_DEBUG ECM-BDWH User’s Manual 31... -
Page 32: Lvds Connector (Jlvds1)
ECM-BDWH 2.4.20 LVDS connector (JLVDS1) Signal PIN PIN Signal +12V +12V LVDS_CLK2_N LVDS_CLK1_N LVDS_CLK2_P LVDS_CLK1_P LVDS_DATA7_N LVDS_DATA6_N LVDS_DATA7_P LVDS_DATA6_P LVDS_DATA5_N LVDS_DATA4_N LVDS_DATA5_P LVDS_DATA4_P LVDS_DATA3_N LVDS_DATA2_N LVDS_DATA3_P LVDS_DATA2_P LVDS_DATA1_N LVDS_DATA0_N LVDS_DATA1_P LVDS_DATA0_P +3.3V +3.3V 32 ECM-BDWH User’s Manual... -
Page 33: On-Board Box Header For Usb3.0 (Jusb3/4)
USB3_RXN4_L USB3_RXP3_L USB3_RXP4_L USB3_TXN3_L USB3_TXN4_L USB3_TXP3_L USB3_TXP4_L USB_PN_Z_4 USB_PN_Z_6 USB_PP_Z_4 USB_PP_Z_6 2.4.22 On-board box header for USB3.0 (JUSB5/6) Signal PIN PIN Signal USBVCC USBVCC USB3_RXN5_L USB3_RXN6_L USB3_RXP5_L USB3_RXP6_L USB3_TXN5_L USB3_TXN6_L USB3_TXP5_L USB3_TXP6_L USB_PN_Z_8 USB_PN_Z_10 USB_PP_Z_8 USB_PP_Z_10 ECM-BDWH User’s Manual 33... -
Page 34: On-Board Box Header For Usb2.0 (Jusb7/8)
ECM-BDWH 2.4.23 On-board box header for USB2.0 (JUSB7/8) Signal PIN PIN Signal USBVCC USBVCC USB_PN_Z_13 USB_PN_Z_12 USB_PP_Z_13 USB_PP_Z_12 2.4.24 PS/2 keyboard & mouse connector (JKB/ MS1) Signal PIN PIN Signal KBDT KBCK KBVCC MSDT MSCK 34 ECM-BDWH User’s Manual... -
Page 35: Audio / Usb Daughter Board User's Guide
Phone Jack LINEIN1 Line in connector Phone Jack AJAUDIO1 Audio connector 6 x 2 header, pitch 2.00mm AJUSB2 2.00mm USB connector 5 x 2 header, pitch 2.00mm AJUSB3 2.00mm USB connector 10 x 2 header, pitch 2.00mm ECM-BDWH User’s Manual 35... -
Page 36: Setting Jumper And Connector
USB2VCC AFRONT1-L-OUT AFRONT1-R-OUT AUSB_PN2 AUSB_PN1 AUSB_PP2 AUSB_PP1 ALINE1-L-IN ALINE1-R-IN AMIC1-L-IN AMIC1-R-IN ALINE1-JD AFRONT1-JD AMIC1-JD 2.00mm USB Connector (AJUSB3) Signal PIN PIN Signal AUSBVCC2 AUSB3_RXN1_L AUSBVCC3 AUSB3_RXP1_L AUSB3_RXN2_L AUSB3_RXP2_L AUSB3_TXN1_L AUSB3_TXP1_L AUSB3_TXN2_L AUSB3_TXP2_L AUSB_PN3 AUSB_PP3 AUSB_PN4 AUSB_PP4 36 ECM-BDWH User’s Manual... -
Page 37: Bios Setup
User’s Manual 3. BIOS Setup ECM-BDWH User’s Manual 37... -
Page 38: Introduction
OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. Remove all storage can also enter the BIOS Setup Utility. 38 ECM-BDWH User’s Manual... -
Page 39: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. ECM-BDWH User’s Manual 39... -
Page 40: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 40 ECM-BDWH User’s Manual... -
Page 41: Bios Setup
Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. ECM-BDWH User’s Manual 41... -
Page 42: System Language
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 42 ECM-BDWH User’s Manual... -
Page 43: Advanced Menu
This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 3.6.2.1 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. ECM-BDWH User’s Manual 43... - Page 44 Enhanced C1 state Enhanced C1 state. Enabled[Default] Disabled CPU C3/6 Report Enable/Disable CPU C3/6 report to OS. Enabled[Default] Short[Default] C6 Latency Configure Short/Long latency for C6. Long Disabled[Default] Intel TXT(LT) Support Enables or Disables Intel® TXT(LT) support. Enabled 44 ECM-BDWH User’s Manual...
-
Page 45: Apci Settings
Disabled[Default] System wake up by ring (from Wake Up by Ring Enabled S3~S5). Disabled[Default] 30 sec 40 sec 50 sec Select Watch Dog Timer (WDT) Watch Dog 1 min Mode. 2 min 10 min 30 min ECM-BDWH User’s Manual 45... -
Page 46: Platform Information
ECM-BDWH 3.6.2.3 Platform Information 3.6.2.3.1 Intel TXT Information 46 ECM-BDWH User’s Manual... -
Page 47: Intel Rc Drivers Version Detail
User’s Manual 3.6.2.3.2 Intel RC Drivers Version Detail 3.6.2.4 Super IO Configuration You can use this item to set up or change the IT8518 Super IO configuration. Please refer to 3.6.2.4.1~2 for more information. ECM-BDWH User’s Manual 47... -
Page 48: Serial Port 1 Configuration
Auto[Default] IO=3F8h; IRQ=4; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; Select an optimal setting for Change Settings IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; Super IO Device. IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; UART 232[Default], Change the Serial Port as UART 232 422 485 UART 422, RS232/422/485. UART485 48 ECM-BDWH User’s Manual... -
Page 49: Serial Port 2 Configuration
3.6.2.4.2 Serial Port 2 Configuration Item Option Description Enabled[Default] Enable or Disable Serial Port Serial Port Disabled (COM) Auto[Default] IO=2F8h; IRQ=3; IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; Select an optimal setting for Change Settings IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; super IO Device. IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; ECM-BDWH User’s Manual 49... -
Page 50: Pch-Fw Configuration
ECM-BDWH 3.6.2.5 PCH-FW Configuration Item Description Firmware Update Configuration Configure Management Engine Technology Parameters. 3.6.2.5.1 Firmware Update Configuration Item Options Description Enable/Disable Me FW Image Re-Flash Disabled[Default] Me FW Image Re-Flash function. Enabled 50 ECM-BDWH User’s Manual... -
Page 51: Amt Configuration
This option just controls the Disabled BIOS extension execution. If enabled, this requires additional firmware in the SPI device Disabled[Default] OEMFLag Bit 15: Un-Configure ME without Un-Configure ME Enabled password Disabled[Default] Disable ME Set ME to Soft Temporary Disabled. Enabled ECM-BDWH User’s Manual 51... -
Page 52: H/W Monitor
ECM-BDWH 3.6.2.7 H/W Monitor Displays system health status Item Description Smart Fan Function Enable or Disable Smart Fan. The following system temperature, fan speed and voltage are monitored. Temperature: 52 ECM-BDWH User’s Manual... -
Page 53: Smart Fan Mode Configuration
CPU Smart Fan Mode Select (Manual, Mode Mode 07/Mode 08/Mode 09/ CPU Smart Fan Mode 1~ Mode 20). Mode 10/Mode 11/Mode 10/ Mode 12/Mode 13/Mode 14/ Mode 15/Mode 16/Mode 17/ Mode 18/Mode 19/Mode 20 Fan PWM (0-255) Fan PWM duty (0-255). 0-255[Default] ECM-BDWH User’s Manual 53... -
Page 54: S5 Rtc Wake Settings
ECM-BDWH 3.6.2.8 S5 RTC Wake Settings 54 ECM-BDWH User’s Manual... - Page 55 Select 0-23 For example enter 3 for 3am and Wake up minute 0-23 15 for 3pm. Select 0-23 For example enter 3 for 3am and Wake up second 0-23 15 for 3pm. Wake up minute increase 1-5. ECM-BDWH User’s Manual 55...
-
Page 56: Serial Port Console Redirection
ECM-BDWH 3.6.2.9 Serial Port Console Redirection Item Options Description Enabled Console Redirection Console Redirection Enable or Disable. Disabled[Default] 3.6.2.10 SATA Configuration It allows you to select the operation mode for SATA controller. 56 ECM-BDWH User’s Manual... -
Page 57: Thermal Configuration
Gen3 Enabled[Default] Port 0/1/4 Enable or Disable SATA Port. Disabled Identify the SATA port is connected to Solid Hard Disk Drive[Default] SATA Device Type Solid State Drive State Drive or Hard Disk Drive. 3.6.2.11 Thermal Configuration ECM-BDWH User’s Manual 57... -
Page 58: Platform Thermal Configuration
This item sets the TSP value for the ACPI Passive Cooling Formula. It represents in 2 – 32 Passive TSP Value tenths of a second how often the OS will 10[Default] read the temperature when passive cooling is enabled. Range 2 – 32. 58 ECM-BDWH User’s Manual... -
Page 59: Network Stack
IPV4/6 PXE boot option will not Disabled be created. Wait time to press ESC key to abort the PXE boot wait time PXE boot. Number of times presence of media will Media detect count be checked. ECM-BDWH User’s Manual 59... -
Page 60: Csm Configuration
Legacy[Default] Do not launch Controls the execution of UEFI and Video UEFI Legacy Video OpROM. Legacy[Default] Do not launch Determines OpROM execution policy for Other PCI devices UEFI[Default] devices other than Network, Storage, or Legacy Video. 60 ECM-BDWH User’s Manual... -
Page 61: Usb Configuration
Mass storage device emulation type. ‘AUTO’ Auto[Default] Floppy enumerates devices according to their media Mass Storage Devices Forced FDD format. Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. ECM-BDWH User’s Manual 61... -
Page 62: Chipset
ECM-BDWH 3.6.3 Chipset 3.6.3.1 System Agent (SA) Configuration Item Options Description Enabled[Default] VT-d Check to enable VT-d function on MCH. Disabled 62 ECM-BDWH User’s Manual... -
Page 63: Graphics Configuration
[480M] [512M] [1024M] [128M] Select DVMT5.0 Total Graphic Memory size DVMT Total Gfx Mem [256M] [Default] used by the Internal Graphics Device. [MAX] Enabled[Default] Gfx Low Power Mode This option is applicable for SFF only. Disabled ECM-BDWH User’s Manual 63... -
Page 64: Lcd Control
Port-D:LFP Driven by Int-DisplayPort encoder from Port-D9through PCH). 1024x768 24/1[Default] 800x600 18/1 1024x768 18/1 1366x768 18/1 1024x600 18/1 Port-EDP to LVDS (Chrotel7511) Panel CH7511 EDID Panel Option EDID Option. 1280x800 18/1 1920x1200 24/2 640x480 18/1 800x480 18/1 1920x1080 18/2 64 ECM-BDWH User’s Manual... -
Page 65: Memory Configuration
200 Hz[Default] 300 Hz 400 Hz 500 Hz 700 Hz LVDS Back Light PWM 1 kHz Select LVDS back light PWM Frequency. Frequency 2 kHz 3 kHz 5 kHz 10 kHz 20 kHz 3.6.3.1.2 Memory Configuration ECM-BDWH User’s Manual 65... -
Page 66: Pch-Io Configuration
2.75 GB 3 GB 3.25 GB 3.6.3.2 PCH-IO Configuration Item Options Description Enabled[Default] PCH LAN Controller Enable or disable onboard NIC. Disabled Enabled Only effected on Mini PCIe with WLAN Mini PCIe WLAN Enable Disabled[Default] adapter. 66 ECM-BDWH User’s Manual... -
Page 67: Pci Express Configuration
PCI Express Configuration 3.6.3.2.1.1 PCI Express Root Port 1 Item Option Description Enabled[Default] PCI Express Root Port 1 Control the PCI Express Root Port. Disabled Set the ASPM Level: Force L0s – Force ASPM Support Disabled ECM-BDWH User’s Manual 67... -
Page 68: Usb Configuration
USB Precondition Disabled root ports for faster enumeration. Smart Auto Auto[Default] XHCI Mode Mode of operation of xHCI controller. Enabled Disabled USB Ports Per-Port Disable Enabled Control each of the USB ports (0~13) Control Disabled[Default] disabling. 68 ECM-BDWH User’s Manual... -
Page 69: Pch Azalia Configuration
Control Detection of the Azalia device. Disabled Disabled = Azalia will be unconditionally Azalia Enabled[Default] disabled. Enabled = Azalia will be Auto unconditionally Enabled. Auto = Azalia will be enabled if present, disabled otherwise. 3.6.3.2.4 BIOS Security Configuration ECM-BDWH User’s Manual 69... -
Page 70: Security
ECM-BDWH Item Options Description Disabled[Default] BIOS Lock Enable or disable BIOS lock enable (BLE) bit. Enabled 3.6.4 Security Administrator Password Set setup Administrator Password User Password Set User Password 70 ECM-BDWH User’s Manual... -
Page 71: Secure Boot Menu
User mode with enrolled Platform Disabled[Default] Key (PK) 2.CSm function is disabled. Secure Boot mode selector. ‘Custom’ Mode Standard Secure Boot Mode enables users to change Image Execution Custom[Default] policy and manage Secure Boot Keys. 3.6.4.1.1 Key Management ECM-BDWH User’s Manual 71... -
Page 72: Boot
Enables or disables boot with Disabled[Default] initialization of a minimal set of devices Fast Boot Enabled required to launch active boot option. Has no effect for BBS boot options. Boot Option #1/2 Sets the system boot order 72 ECM-BDWH User’s Manual... -
Page 73: Save And Exit
The setup program then exits and reboots the controller. 3.6.6.3 Restore Defaults This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. ECM-BDWH User’s Manual 73... -
Page 74: Drivers Installation
ECM-BDWH 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 74 ECM-BDWH User’s Manual... -
Page 75: Install Chipset Driver
Windows 8 operation system. If the warning message appears while the installation Step 3. Click Install. process, click Continue to go on. Step 4. Click Finish to complete setup. Step1. Click Next.. Step 2. Click Accept. ECM-BDWH User’s Manual 75... -
Page 76: Install Me Driver
If the warning message appears while the installation process, click Continue to go on. Step 3. Click Next to proceed setup. Step1. Click Next to start installation. Step 4. Click Finish to complete setup. Step 2. Click Next. 76 ECM-BDWH User’s Manual... -
Page 77: Install Usb 3.0 Driver
Step 3. Click Next to continue installation. process, click Continue to go on. Step 4. Click Next to continue installation. Step1. Click Next to start installation. Step 2. Click Yes. Step 5. Click Finish to complete setup. ECM-BDWH User’s Manual 77... -
Page 78: Install Vga Driver
Owing to the first priority of display is LVDS, it occur two screens (VGA + HDMI Monitor) disappears after install the OS & VGA driver at first time. Please unplug the HDMI Cable and then continue installing Driver, the Monitor can be working normally. 78 ECM-BDWH User’s Manual... -
Page 79: Install Audio Driver (For Realtek Alc892)
\Driver_Audio\Realtek\ALC892\ECM-BDWH_Audio. Note: The installation procedures and screen shots in this section are based on Windows 8 operation system. Step 1. Click Next to continue setup. Step 2. Click Finish to complete the setup. ECM-BDWH User’s Manual 79... -
Page 80: Install Ethernet Driver (For Intel I210At And I217Lm)
Step 3. Click Next. Windows 8 operation system. Step 1. Click Next. Step 4. Click Install to proceed. Step 2. Click Next to accept license Step 5. Click Finish to complete the agreement. setup. 80 ECM-BDWH User’s Manual... -
Page 81: Mechanical Drawing
User’s Manual 5. Mechanical Drawing ECM-BDWH User’s Manual 81... - Page 82 ECM-BDWH Unit: mm 82 ECM-BDWH User’s Manual...
- Page 83 User’s Manual Unit: mm ECM-BDWH User’s Manual 83...
