- Page 1 Day to Day Tables – Steel Base T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com...
-
Page 2: Revision Log
Day to Day Tables – Revision Log Steel Base Date Page Description of change Name 6/22/2018 Released S. Powers 12/12/18 Added AIS Power Unit Instruction S. Powers T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com... - Page 3 42H for Caster 37.749 42H for Glide 38.749 Flat head wood screw Foam Block #9 x 7/8 long with #2 Phillips drive silver x 12 Worksurface X-Base Glide RC-ELBOLT1 Caster RC-CASTER-B 5/8” Hex Head Long Bolt T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com...
- Page 4 Corner and 120 Tables 6” 6” Caster RC-CASTER-B Glide Glide Caster RC-ELBOLT1 3” 3” Worksurface 2” 3” 3” 3” 3.5” 2” Flat head wood screw #9 2” x 7/8 long with #2 Phillips drive, silver x 12 T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com...
- Page 5 Corner and 120 2” 2” Caster RC-CASTER-B 2” Glide 2” Glide Caster RC-ELBOLT1 3.5” Worksurface 2” 2” SURFACE DIM A Flat head wood screw #9 3.5” x 7/8 long with #2 5” Phillips drive, silver x 12 T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com...
- Page 6 Day to Day Tables – U-Channel Assembly Steel Base U-Channel (See following page for location) Flat head wood screw #9 x 7/8 long with #2 Phillips drive, silver x 12 T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com...
- Page 7 84W use TL-UCK48 24-30D 60W use TL-UCK48 42W use TL-UCK54 66W use TL-UCK54 48W use TL-UCK60 72W use TL-UCK60 54W use TL-UCK66 42-48W U-Channel Length 36” TL-UCK36 42” TL-UCK42 48” TL-UCK48 54” TL-UCK54 60” TL-UCK60 66” TL-UCK66 T-SBTINSTALL Revision 12.12.2018 www.ais-inc.com...
- Page 8 Day to Day Tables – AIS Power Unit Steel Base Power Cover #6 x 3/8” Flat Head Sheet Metal Screw 2 Places Power Unit Power Box Plug 2 Places Data Jack 2 Places #9 x 7/8 long Flat head wood screws...
