Calibrate Installation
#8 x ¾" long
Flat head wood screw
Philips Drive #2
RH-WSFP834
Install Bottom Brackets
A-WMTBB
to Hutch using #10 x ¾" long
Flat head wood screw
Philips Drive #2
RH-WSFP1034
Install Top
Bracket
A-WMTBB
onto Tackboard
Bottom
Brackets
Hutch Mount Tackboards
Tool Rail
RL-TRxx
Remove tape backing
from top brackets prior
to installing tackboards
Tackboard
C-CXTBINSTALL Revision date 09-20-2017
Tackboard
Tool Rail
Hutch
