Summary of Contents for SelectBlinds Fashion Color Power Touch Series
- Page 1 Roller Shades Fashion Color Collection Light Filtering Roller Shades POWER TOUCH RECHARGEABLE Installation & Care Instructions 152733 4/19/2017...
- Page 2 GETTING STARTED A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄ ” Hex head and/or Phillips driver bit PN: CS5002(W or BLK) - #2 Phillips head screwdriver CS5008 (W or BLK) CS5529 - Pencil CS5530 Depends on size of shade...
- Page 3 INSIDE MOUNT ” The minimum mounting depth for an inside mount is 1 ⁄ ” A minimum of 3 is needed to fully recess the shade. ” Make sure the brackets are level and aligned. Attach using two screws. Inside Mount ”...
- Page 4 SHADES WITH NO HEAD RAIL The installation brackets are always mounted so that the Idler Side Bracket Motor Side bracket inner surfaces face each other. T-Hook Brackets must be in line and level. Shim brackets on inside mounts if necessary. The head rail must be level for the shade Foot to operate properly.
- Page 5 SHADES WITH NO HEAD RAIL Insert the foot of the motor-side bracket into the slotted center hole of the motor end of the fabric roll. Support Bracket Set the post of the idler end into the V of the support bracket. Rotate the T-hook on the support bracket to lock in the post and secure the fabric roll.
- Page 6 ADJUST MOTOR LIMITS (IF DESIRED) The upper and lower limits have been set at the factory. If you need to make adjustments to the limits, follow the instructions below. Press the SETTING button on the back of the wand and hold it in until the motor stops beeping.
- Page 7 SKEW ADJUSTMENT (IF NECESSARY) If the shade does not raise evenly, first make sure the mounting brackets are mounted level with each other. If the shade is level and it still skews, roll the shade all the way down. Prepare a strip of masking tape approximately 5”...
-
Page 8: Troubleshooting
CHARGING THE MOTOR BATTERY When the shade begins to operate slower than normal, or only beeps when you attempt to operate, it is time to charge the battery. Plug the 8.4v charger into the port on the wand. Plug the charger into an electrical outlet. Charging Port A red light on the charger indicates that the battery is charging. - Page 9 Roller Shades MOTORIZED SHADE Simplicity with rechargeable motor 152709 D Installation & Care Instructions 10/4/2017...
-
Page 10: Getting Started
GETTING STARTED IMPORTANT: The remote control has not been linked to the shades. Install all shades prior to linking the remote. A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄ ” Hex head and/or Phillips driver bit - Pencil Additional fasteners other than those sent with your shade may be required depending on the mounting surface. -
Page 11: Step 1: Bracket Installation
STEP 1: BRACKET INSTALLATION Important: If a solar recharge unit is being installed read the section on solar recharge on page 20 prior to installing mounting brackets. SHADES WITH HEAD RAIL Shades are shipped with the required number of brackets for proper installation. End brackets should be located approximately 3”... -
Page 12: Outside Mount
OUTSIDE MOUNT The minimum mounting height for outside ” mounted shades is 1 ” Make sure the brackets are level and aligned. Outside Mount Attach using two screws. Minimum 1” surface SPACER BLOCKS (OPTIONAL) ⁄ ” Each spacer block projects brackets away from mounting surface. - Page 13 SHADES WITH NO HEAD RAIL The installation brackets are always mounted Idler Side Bracket Motor Side bracket so that the inner surfaces face each other. T-Hook Brackets must be in line and level. Shim brackets on inside mounts if necessary. The Foot head rail must be level for the shade to operate properly.
- Page 14 STEP 3: LINK REMOTE The remote control has multiple channels. Before linking the remote, determine which shade(s) you want on which channel. The standard remote has 5 channels, the remote with timer has 6 channels. All shades linked to Setting a remote will also automatically be (red button) Setting...
-
Page 15: Operation
OPERATION STANDARD REMOTE Channel Display Select the desired channel with the CHANNEL buttons. The channel indicator light will illuminate the channel Stop/Favorite that is on. If all 5 lights are lit, the remote will control all Down 5 channels at once. Channel + Channel - Tapping the UP or DOWN buttons for less than 2... - Page 16 ADJUST MOTOR LIMITS (IF DESIRED) If using a timer remote, tap the clock button until you see “MANUAL” in the display. The lower and upper limits have been set at the factory. If you need to make adjustments to the limits, follow the instructions below. Please Note: When clearing the factory set limits, both the upper and lower limits will need to be reset.
-
Page 17: Lower Limit
LOWER LIMIT Hold the LIMIT button until the shade stops jogging. Use the DOWN button to lower the shade. Press stop when the shade is near the desired lower limit. Use the UP and DOWN buttons to adjust the length more accurately. Hold the CONFIRM button until the shade jogs. - Page 18 FAVORITE POSITION When adding a favorite position to one shade, the other shades on that channel need to be temporarily unlinked from the remote. To unlink a shade, press and hold the Setting SETTING button until it completes (red button) Setting one jog - jog/jog cycle and then (red button)
- Page 19 CHANGING A FAVORITE POSITION Unlink all other shades on the same channel before changing/erasing the favorite position. Use the UP or DOWN buttons to position the shade at the desired “favorite” position. While holding the LIMIT button, quickly press and hold the UP button.
-
Page 20: Advanced Programming
ADVANCED PROGRAMMING REPLACE ORIGINAL REMOTE, ADD ADDITIONAL REMOTE OR ADD SHADE TO AN ADDITIONAL CHANNEL 1. Press the SETTING button on the motor until the shade jogs once. Release the button immediately after the first jog - this should not be more than 3 seconds. Setting (red button) Setting... - Page 21 REMOVE A SHADE FROM A REMOTE OR CHANNEL AND LINK IT TO A DIFFERENT REMOTE OR CHANNEL 1. Press and hold the SETTING until it completes one jog - jog/jog cycle. 2. Release the “Setting” button. The original remote or channels have been unlinked.
-
Page 22: Setting Clock
PROGRAMMING TIMER REMOTE SETTING CLOCK Use the power button to turn on the remote. Display Screen Tap the CLOCK button until you see Power MANUAL 06:42 Button “MANUAL” in the display. Stop/Favorite Down Push and hold the LIMIT button. While Channel holding the LIMIT button, push the CLOCK button for 3 seconds and release. - Page 23 SETTING TIMER SCHEDULES Display Screen The timer remote allows up to 18 different Power MANUAL 06:42 Button timer schedules. Each timer schedule can Stop/Favorite be set for multiple channels and days, but Down only one function can happen at each time. Channel Use the power button to turn on the remote.
- Page 24 Use the STOP button to select the day and move on to the next one. Use the = Select STOP UP arrow to skip a channel and the Auto FF:FF = Confirm DOWN arrow to back up. You must press STOP for each day that you want to select.
-
Page 25: Important Notes
IMPORTANT NOTES • Remote must be in “AUTO” mode for the set schedules to operate. To return to “MANUAL” mode, tap the CLOCK button. • When remote is in Auto mode, the display will alternate between the current time/day and the time/day/channel for the next upcoming schedule. •... - Page 26 HOLD DOWN BRACKETS (OPTIONAL) Optional hold down brackets are mounted with the supplied screws. With the shade at its proper drop, place the pin of each hold down into the hole in each end cap and mark the screw holes. Make sure the pins are level and aligned.
-
Page 27: Replacing The Battery In The Remote
REPLACING THE BATTERY IN THE REMOTE STANDARD REMOTE Remove the battery tray from the remote by inserting a fingernail into the indentation on the back of the remote. To avoid the battery falling out of the remote, remove the tray while the remote is face up. Insert the new battery (CR2430 lithium) into the battery tray so that the writing is facing up (positive up) when the remote is face up. -
Page 28: Cleaning And Care
SHADE REMOVAL If you need to remove your shade, follow the instructions below. Partially lower the shade and insert a flat head screwdriver as shown. Twist the screwdriver until the head rail disengages from the bracket. As you release the brackets, support the head rail to keep it from falling. - Page 29 SOLAR RECHARGE UNIT (OPTIONAL) DETERMINE SOLAR RECHARGE UNIT PLACEMENT The solar recharge unit should be placed where is gets the maximum amount of sunlight per day. In most cases this can be achieved by mounting the unit directly to the glass with double sided tape. Brackets are provided if attaching to the glass is not possible.
- Page 30 Inside Mount with Top Outside Mount Reversed The top portion of the This method will provide the bracket may be reversed least amount of sun exposure. if necessary depending on Bracket can be mounted next space. to shade mounting bracket. Bracket can be mounted behind or next to shade mounting bracket.
- Page 31 INSTALL SOLAR RECHARGE UNIT Tape Method Cut the tape (part # MI051045) to fit inside the white border as shown. Clean the ends of the solar panel where the tape will go with rubbing alcohol. When dry, remove the release liner from one side of the double sided tape and adhere them to face of the panel.
