SelectBlinds Basswood Blind Installation Instructions

2" & 2 1/2" Basswood & Fauxwood
Blind Installation Instructions
Please follow these Installation Instructions
You will need a pencil, tape measure, drill, screwdriver, pliers, and appropriate fasteners.
Step 1: Choose the Correct Fastener
Wood Screws (Included)
Step 2: Prepare Brackets
End Box
Installation Brackets
Prepare box brackets for installation:
Open the front of the bracket by
pressing on the bottom of the
bracket to release the locking
tab while lifting the front gate.
Step 3: Mark the Bracket Locations
(For Outside Mount Installations)
Position the box brackets at each end of the headrail. When using a
single center support bracket, center it between the box brackets. For
more than one center support bracket, space the support brackets
evenly, not more than 30" apart. Make sure the brackets will not
interfere with the cord mechanism or any other internal parts. Mark
the bracket for mounting hole locations, making sure they are square
and equally spaced. For outside mount installations, use a level to
check for levelness.
1 ½" #8 Hex Head
Use the following # of Center Support Installation Brackets based on the Blind Width:
Center Support
Bracket
Alternative fasteners should be used for aluminum or
Up to 24" 24 ⅛" - 36"
0 1
Up to 47.99" 48" - 71.99" 72" - 95.99" 96" - 119.99" 120" +
2 3
For your convenience, extra valance clips are included.
For Inside Mount Installations)
Position the box brackets at each end of the headrail. Depending on the
installation location, box brackets can be attached using the top, back,
or side holes. When using a single center support bracket, center it
between the box brackets. For more than one center support bracket,
space the support brackets evenly, not more than 30" apart. Make sure
the brackets will not interfere with the cord mechanism or any other
parts. Mark the location of the desired bracket mounting holes, making
sure that they are square and equally spaced.
concrete installations
(Not Included with Blinds)
36 ⅛" - 60
2
Valance Clips Needed
4 5
Greater than 60"
3
6
